Tessera Outline - Tufted carpet tile

Name: Tessera Outline - Tufted carpet tile
Brand: Forbo Flooring Systems
SKU: sw8sPhywscmM36rm9krxqz

Verified by manufacturer 12 days ago

Third party certifications:

A collection of eight contemporary, two colour striped designs, four of which are also available as 100 x 25 cm planks.

Jump to:

Application

For internal use in all busy commercial and public sector locations.

Subtly textured, tufted, striped, low loop pile carpet tile.

Features and benefits:

Made with 100% renewable electricity.
Investment in an extruder has reduced bitumen usage by 50%.
Also available in SOFTbac® secondary backing.
Manufactured from 100% solution-dyed nylon 6.
Combinations of Outline and Layout allow complete freedom of expression when creating connections, highlights and transitions, enhancing any style of scheme.

Method of laying:

Brick, tessellated, quarter turn or quarter brick.

Adhesive:

542 Eurofix Tack Plus solvent free release system.

Color	Black Brown Grey
Finish	Tufted
Material	Nylon
Shape	Square
Length	500 mm
Width	500 mm
Height	5.8 mm
Warranty description	Ten year Manufacturer guidance Standard backing: 10 years; SOFTbac® backing: 15 years

Uniclass	Pr_35_57_11_62 Pile carpet tilesPrimary
CAWS	M50/130 Carpet tiling M50/15 Carpet tiling

Product range	Tessera Carpet Tiles

Style	Tufted low loop pile carpet tile.
Material	100% solution dyed Nylon 6.
Classification	-
Standard	To BS EN 1307 and 14041.
Level of use class	Class 33.
Recycled content	61.77%.
Size	500 x 500 mm.
Colour and pattern	3100 Plasmatron. 3101 Colabottle. 3102 Soda. 3103 Ripple. 3104 Souffle. 3105 Macaroon. 3106 Fruitsalad. 3107 Bubblegum.

Total thickness	5.8 mm ±10%.
Pile composition	100% polyamide 6.
Dye method	100% solution dyed.
Stitch density	193 060 per m² ±10%.
Pile weight after shearing	580 g/m² ±10%.
Total weight	3895 gsm ±10%.
Castor chair use (to BS EN 985)	Minimum R value: ≥2.4.
Light fastness (to BS EN ISO 105 B02)	≥7.
Dimensional stability (to BS EN 986)	≤0.2%.
Impact sound reduction	27 dB.
Ska Rating	Create Outline meets Ska Rating Criteria for M12 soft floor coverings in both office and retail schemes.
Reaction to fire (to EN 13501-1)	BfI-s1.
Slip resistance (to EN 13893)	DS: ≥0.30.
Static dissipative (to BS ISO 10965)	<1 x 10^9 Ω.
Body Voltage (to EN 1815)	Pass (<2 kV).
Pile height above backing	2.9 mm ±0.5 mm.
Primary backing	Polyester/ nylon.
Secondary backing	Modified bitumen and polyester fleece- standard. SOFTbac®.
Adhesive	Not required. Eurocol 542 Eurofix Tack Plus solvent free release system. IOBAC MagTabs® adhesive free installation system.
Edging	Not required. As per 740.

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Nylon
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	3.48 kg CO₂ eq/m²
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	62 %
