Tecno-Sil 619 Construction Silicone Sealant

Tecno-Sil 619 Construction Silicone Sealant

FSi Limited Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

One-part, neutral curing, low modulus silicone sealant.

Jump to:
+44 (0)1530 515130 www.fsiltd.com
Application

Suitable for alkaline substrates such as concrete, mortar and fibrous cement.

Description

One-part, neutral curing, low modulus silicone sealant with high adhesion for perimeter sealing and glazing applications.

Features and benefits:

  • Cures at room temperature under atmospheric moisture.
  • Produces a permanently flexible silicone rubber.
  • Has a primerless adhesion to most materials.
  • Non-corrosive to metals.
  • Non-sag.
  • Quickly becomes tack free due to rapid crosslinking.
  • Remains flexible at low and high temperatures (-40°C to 150°C).
  • Good weather resistance.
  • Low dirt pick-up.
  • Anti-fungal to prevent mould growth.
  • CE marked.

Applications:

Suitable for alkaline substrates such as concrete, mortar and fibrous cement.

Conforms to/ approved by:

The harmonized European standard, EN 15651, for facade, glazing, cold climate, sanitary and pedestrian walkway applications in compliance with the 'Construction Product Regulation'.

Should not be used as a secondary sealant in insulating glass units or for structural glazing bonding. Not to be used with coating materials (paints and varnishes) or organic plasticizer containing rubbers (EPDM, butyl and neoprene). Not suitable in use with natural stones such as marble, granite or quartzite. Not recommended for long term use under water. Not suitable for food contact applications.

General information

Uniclass 2015

Pr_30_31_76_33 Glazing compounds and sealantsPrimary

CAWS

F11/116 Mortar jointed, sealant pointed glass block walling

F11/121 Sealant jointed glass block walling

F11/141 Sealant jointed glass block walling

F11/410 Perimeter/ Expansion joints with sealant

H11/772 Curtain walling joint assembly sealants

H11/777 Weathersealing for structural sealant/ bonded glazing

L10/75 Sealant joints

L10/810 Sealant joints

L20/820 Sealant joints

L40/230 Bead-fixed single-glazing

L40/250 Bead-fixed single-glazing

L40/310 Bead-fixed single-glazing

L40/330 Bead-fixed single-glazing

L40/350 Bead-fixed single-glazing

L40/372 Bead-fixed insulating glass units

L40/380 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/495 U-profiled single-glazing

L40/496 U-profiled double-glazing

L40/50 Bead-fixed single-glazing

L40/55 Bead-fixed insulating glass units

Specification data - Glazing compounds and sealants

Product Reference

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-1 Class 25LM

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-2 Class 25LM

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-3 Class XS Sealant

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-4 Class 12.5E Sealant

Standard product features

Reaction to fire (to EN 13501-1):

Class E.

Technical characteristics:

  • Application temperature: 5–40°C.
  • Resistance to flow (ISO 7390): ≤1.5 mm.
  • Loss of volume (ISO 15653): ≤9%.
  • Loss of mass (ISO 15653): ≤0.1%.
  • Tensile strength (ISO 8339): ≤0.9 MPa.
  • Tensile properties at maintained extension: ISO 8340: No failure; ISO 10590: No failure.

Product Options

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-2 Class 25LM:

  • Elastic recovery (ISO 7389): ≤90%.
  • Adhesion and cohesion properties (after exposure to heat, water and artificial light through glass at 100% extension, to ISO 11431): No failure.

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-3 Class XS Sealant:

Evaluation of the action of the micro-organisms (ISO 846): 4.

Tecno-Sil 619 Construction Silicone Sealant, EN 15651-4 Class 12.5E Sealant:

Modified tear: No failure.

Consult manufacturer for further information.

Third party certifications
  • 087 : Product Certification
  • Declaration of Performance: TS619-DOP-001
