Tecnica® SEB

Third party certifications:
  • QA Certificate

    Certificate type

FSi Limited

Multi-layered stone wool and thermoplastic composite barrier.

Jump to:
+44 (0)1530515130 www.fsiltd.com
Application

Suitable for use in irregular applications, including:

  • Historical building upgrades.
  • Voids up to 450 mm wide.
  • Rigid floors of 150 mm minimum thickness.

Description

Pre-built, pre-cut, multi-layered barrier designed to prevent the passage of fire between compartment floors at the edge of slabs.

Features and benefits:

  • Offers acoustic isolation and waterproofing.
  • Allows for building movement.
  • There are 16 build-up possibilities within the product range which offer differing engineered solutions and capabilities – consult manufacturer for details.
  • The integrated aluminium foil facings provide class ‘O’ rating and high resistance to smoke.
  • Resilient lateral compression ensures a tight fit.
  • Based on renewable materials and is environmentally sustainable, contributing to green building.
  • Reduces embodied energy.
  • The intumescent material is not affected by moisture.
  • Air and water permeability tested.
  • High speed, easy installation with minimal waste.
  • Single component.
  • No Volatile Organic Compounds (VOCs).
  • No curing time is required.
  • Low maintenance system with long life.
  • Soft to touch, odourless and easy to cut.
  • Free of halogens, asbestos, fibres and silica, and is non-toxic.
  • High speed installation.
  • Can be used in both internal and external applications.
  • Life expectancy of over 25 years.
  • CE marked.

Applications:

Suitable for use in irregular applications, including:

  • Historical building upgrades.
  • Voids up to 450 mm wide.
  • Rigid floors of 150 mm minimum thickness.

Conforms to/ approved by:

  • EN 1366-4.
  • EN 10140.

Brackets should be positioned at 300 mm and 700 mm, and must be fixed to the rigid structure using no combustible fixings. A minimum of two brackets should be used per 1200 mm length.

Consult manufacturer to view performance data in different applications.

General information
Specification data - Mineral wool slab insulation
Product Reference

Tecnica® SEB

Length

Consult manufacturer and inset requirements.

Thickness

100–140 mm. Consult manufacturer and insert requirements.

Acoustic membrane

2–12.5 mm thickness. Consult manufacturer and insert requirements.

Standard product features

Width:

300 mm.

Fire resistance (to BS 476:22):

120 minutes.

Reaction to fire (BS EN ISO 13501-1):

Class A1.

Technical characteristics:

  • Thermal conductivity: 0.35–0.37 W/mK.
  • Density (ISO 2811-1:2011): 80 kg/m³ and 140 kg/m³.
  • Acoustic isolation (EN10140): 33–63 dB (dependent on thickness chosen).
  • Watertightness (EN 1928:2002): 60 kpa.
  • Water absorption (ASTM D 570): No penetration.
  • Adhesion to steel (ASTM D 1000): >250 N.
  • Adhesion to primed concrete (ASTM D 1000): >250 N.
  • Waterproof membrane: 1 mm polyethylene film with self-adhesive compound.
  • Heat aging: No defects at 300°C.

Third party certifications
  • 087 : Product Certification
