Technoelast SBS EPP Underlay

Third party certifications:
  • BBA Agrément Certificate

    Certificate type

TechnoNICOL

Torch-applied, styrene-butadiene-styrene (SBS) modified bituminous underlay.

Jump to:
+44 (0) 1786 451170 www.tnroofingsystems.com/
Application

  • Designed to suit requirements of both new build and remedial roofing applications. It can be applied to all suitable non-combustible substrates as an underlay in built-up waterproofing systems or as a vapour control layer on newly built or refurbished flat roofs.
  • The product can also be used as the top layer in certain built-up ballasted waterproofing systems where there is suitable surface protection. The product is not recommended for use as single layer waterproofing.

Description

A polyester reinforced torch-on underlay, saturated and coated with high quality styrene-butadiene-styrene (SBS) modified bitumen. The membrane carrier is a tough polyester reinforcement, giving the material high dimensional stability and mechanical strength. The membrane is finished on both sides with a thermofusible film for fast and consistent torch-on application.

Features and benefits:

  • Independently tested by the British Board of Agrément.
  • Guided (snowflake print) rapid melt film for accurate and consistent torch-on application.
  • Good low temperature flexibility at -25°C.
  • High puncture resistance.
  • High resistance to foot marking.
  • CE marked.

Applications:

  • Designed to suit requirements of both new build and remedial roofing applications. It can be applied to all suitable non-combustible substrates as an underlay in built-up waterproofing systems or as a vapour control layer on newly built or refurbished flat roofs.
  • The product can also be used as the top layer in certain built-up ballasted waterproofing systems where there is suitable surface protection. The product is not recommended for use as single layer waterproofing.

General information
Specification data
Product Reference

Technoelast SBS EPP Underlay

Standard product features

Size (l x w):

8 x 1 m.

Weight:

4.8 kg/m².

Technical characteristics:

  • Reinforcement type and weight: Polyester, 190 g/m².
  • Tensile properties maximum tensile force (to EN 12311-1): 1000/ 700 N/50mm (±200 /140).
  • Tensile properties elongation (to EN 12311-1): 50/ 50% (±15).
  • Resistance to tearing (nail) (to EN 12310-1): 300/ 350 N (±90/105).
  • Flow resistance at elevated temperatures (to EN 1110): ≥120°C.
  • Flexibility at low temperatures (to DIN to EN 1109): ≤-25°C.
  • Watertightness (to EN 1928): 300 kPa.
  • Water vapour transmission properties (to EN 1931): - µ=20 000.
  • Reaction to fire (to EN 13501-5/ to ENV 1187: 2002, test 4): Broof (t4).
  • Chemical resistance: Water-resistant and is resistant to watery solutions of salt, diluted non-oxidising acids and bases. Aliphatic and aromatic hydrocarbons, as well as chlorine hydrocarbons, oils and greases may loosen the product and should therefore be avoided.
