Technishield 65 EI60 Double Door

Name: Technishield 65 EI60 Double Door
Brand: Optima
SKU: mD7Es8XyzZACj9KdQcz9kS

Verified by manufacturer 15 days ago

Optima

Product certifications:

BM Trada
Certificate type
BM Trada
Certificate type

EI60 fire-rated glass doorset, rebated double door.

Jump to:

+44 (0)1494 492725 Website

Application

For use in conjunction with Technishield 65 partition system.

Description

A framed, rebated, double-leaf, fire-rated glass doorset on hinges.

Features and benefits:

Offering 60 minutes' integrity and insulation.
Part M-compliant clear opening included.

General information

Color	Silver White Other
Finish	Powder-coated
Material	Glass
Warranty description	Three year Guidance for specification option: See Warranty Policy literature for more information.

Uniclass	Ss_25_30_20_25 Doorset systemsPrimary
CAWS	L20/480 Doorsets L20/55 Doorsets

Product range	Fire Range Doorsets

Specification data - Doorset systems

Classification data
System performance	Fire performance.
Doorset	-
Type	Fire rated glass doorset.
Seals or inserts	-
Door	Manufacturer's standard. Guidance for specification option: Dropseal: Type RO drop seals. Door seals: Fire and smoke protection double-seal.
Over panels	Not required. Over panel. Over panel and side panel. Guidance for specification option: Insert requirements.
Side panels	Not required. Side panel both sides. Side panel left side. Side panel right side. Over panel and side panel. Guidance for specification option: Insert requirements.
Hardware	Manufacturer's standard. Guidance for specification option: Hinges: Three face-fitted, weld-on hinges per leaf. Handles: Forster stainless steel lever handle set, fire-rated, cranked U-form steel cored with 9 mm spindle. Lock: Two-point fire-rated lever latch with Euro-cylinder operated deadlock. Euro cylinder: Cylinder and turn – 35 mm/ 35 mm. Door closer: TS-93 2-4. Other. Guidance for specification option: Insert requirements; contact manufacturer for information.
Samples required	Not required. Required.
Finish/ Colour	Powder-coated, RAL. Guidance for specification option: Insert requirement; contact manufacturer for more information. Powder-coated, RAL 9006 Silver. Guidance for specification option: 50 microns, 30% gloss (nominal). Powder-coated, RAL 9010 White. Guidance for specification option: 50 microns, 30% gloss (nominal).
Manifestation	Guidance for specification option: Insert requirements.
Fire rating	EI60 – 60 minutes' integrity and insulation (60/60).
Size	Guidance for specification option: Door: With over-panel: Available 1850–2800 x 2200–4000 mm (w x h); without over-panel: Available 1850–2800 x 1800–2700 mm (w x h). All dimensions subject to specification and certification. Side panel: Available 300–1100 mm in width.
Configuration	As schedule. As drawing. Guidance for specification option: Insert drawing reference number.

Sustainability data

A1–A3 ('Production stage')	Embodied carbon as defined in BS EN 15804
Normalized unit
Declared unit	179 kg CO₂ eq/m² Self-declared Guidance for specification option: See Environmental Product Declaration literature for LCA data.
