Taraflex® Evolution Dry-Tex™- Sheet - Sports flooring

Verified by manufacturer 3 days ago

6350 - Light Cherry

Gerflor Flooring UK Limited Variant:
Third party certifications:
  • EPD

    EPD

    Certificate type

Taraflex® Evolution Dry-Tex™ is a point elastic vinyl sheet sports floor covering, suited to all levels of sport and bonded with a specific adhesive to overcome wet subfloor issues.

Jump to:
BOS
01625 428 922 Website

Application

Suitable for a variety of sports and leisure activities.

Description

Taraflex® Evolution Dry-Tex™ is a multi-purpose vinyl sheet sports floor covering consisting of a D-Max™ surface - Gerflor’s own complex made up of calendered polyvinyl chloride (PVC) sheets reinforced with a fibreglass grid for high durability and outstanding dimensional stability. It is backed with double density CXP HD™ closed cell foam for performance and safety. Taraflex® Evolution Dry-Tex™ has a patented technology textile backing that combines with GERPUR adhesive from Gerflor to enable bonding to wet subfloors. Taraflex® Evolution Dry-Tex™ is subject to a minimum order quantity.


Features and benefits:

  • P1 shock absorption category sports floor (EN 14808).
  • Impact Protection Index (IPI) of 76% for medium protection to users falling, sliding or diving on the floor.
  • Triple Action Protecsol® surface treatment for easy maintenance, friction burn protection and ‘intelligent’ sliding coefficient.
  • Available in 20 solid colours and wood designs as standard. A further 127 solid colour options and bespoke digitally printed options are available, subject to a minimum order quantity.
  • Combine with GERPUR adhesive for wet subfloor installation.
  • 100% recyclable.
  • As used by many leading International Sport Federations –contact manufacturer for full list.
  • Also available as Taraflex® Evolution for standard installation conditions and Taraflex Evolution SL - an adhesive-free solution. (specified separately).


Installation and maintenance:

Installation and maintenance instructions are available; consult manufacturer for details.

General information

Color

Beige

Black

Blue

Gold

Green

Show more

Material

Vinyl

Length

26500 mm

Guidance for specification option:

Maximum roll length.

Width

1500 mm

Height

7.5 mm

Warranty description

12 year

Uniclass

Pr_35_57_71_32 Foam-backed polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Product range

Sports Flooring / Gym Flooring
Sports Flooring / Vinyl Sports Flooring
Sports Flooring / Health/Fitness Flooring
Sheeting / Vinyl Sports Flooring

Specification data - Foam-backed polyvinyl chloride (PVC) sheets

Standard

To EN 14904.

Width

1500 mm.

Thickness

7.5 mm.

Colour and pattern

6350 Light Cherry.

Weight

4.7 kg/m².

Abrasion resistance

≤350 mg.

Fire classification (EN 13501-1)

Cfl-s1.

Impact resistance

≥8 N/m.

Guidance for specification option:

To EN 1517.

Resistance to indentation (minimum)

≤0.5 mm.

Guidance for specification option:

To BS EN 1516.

Accessories

None.

Co-ordinating weld rods.

My Taraflex® bespoke digital print service.

Guidance for specification option:

Contact manufacturer for details and insert requirements.

Ball rebound

≥90%.

Guidance for specification option:

Ball bounce to BS EN 12235.

Sliding properties

80–110.

Guidance for specification option:

To BS EN 13036-4 Sliding coefficient.

Deformation capability

≤ 2.0 mm.

Guidance for specification option:

To BS EN 14809 Vertical deformation.

Shock absorption

P1.

Guidance for specification option:

To EN 14808.

Impact protection (minimum)

76%.

Guidance for specification option:

Impact Protection Index (IPI) to AC-P90-205.

Surface treatment

Triple Action Protecsol.

Light reflectance value (LRV)/ Colour

43.3.

Sustainability data

Contains Red List materials

No

Material

Vinyl

Recyclability

100%

Third party certifications
