System 8 Low-Rise Curtain Walling

Verified by manufacturer 8 months ago

Metal Technology Ltd Third party certifications:
  • EPD

    EPD

    Certificate type

  • CWCT Certificate

    CWCT Certificate

    Certificate type

  • ISO 45001 Health and Safety Management

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

A highly efficient, thermally enhanced aluminium framed low rise curtain walling system.

Jump to:
+44 (0)28 9448 7777 Website

Application

Suitable for ground and first floor applications. Traditionally used for low level glazing only., which can accept glass, panels and other opening sections e.g. doors or windows.

Description

Primarily developed for ground and first floor applications, but may be installed at any level on a building provided the maximum height of each screen does not exceed 6 m, and subject to the structural sections being designed to accommodate the applicable loads in accordance with the relevant site conditions and application.


Features and benefits:

  • Thermal: Metal Technology’s Curtain Walling Range, in conjunction with the correct glass specification, is designed to aid compliance with the latest thermal requirements of the current building regulations. The thermal isolator profile has been specifically designed to minimise heat transfer across the mullion and transom.
  • Weathertightness: Class III to BS 6375-1:1989 and BS 5368.
  • Design Wind Pressure: To be in accordance with BS 6399-2:1997.
  • Deflection: All structural profiles can be designed so that maximum deflection of any member shall not exceed L/200 of its span, with no evidence of any permanent deformation once the load has been removed.
  • The full range of Metal Technology Ltd’s windows and doors can be incorporated into the system.
  • Glazing: The system is externally glazed and can accommodate glazing units from 6 mm to 36 mm.
  • Dry glazed using proprietary, high performance captive gaskets. All gaskets to be bonded and sealed during construction, using waterproof adhesive.


Construction:

Fabricate the system in ladder modules using a two-piece mullion assembly snapped together on site. Square cut the frame members and fix securely to the frame with stainless steel screws driven into integral screw ports within the sections. Seal all frame joints during construction against entry of water using a small gap sealant with glazing tape applied over the front face of each joint. The manufacturer recommends that only A2 or A4 austenitic stainless steel fixing screws are used in the assembly of their products.



Carefully designed fixing brackets have been developed for System 8 to allow a secure and simple fix so that all loads can be transferred back to the building’s main structural form with ease.

General information

Color

Beige

Black

Blue

Bronze

Brown

Show more

Finish

Powder-coated

Guidance for specification option:

Gloss, Matt or Satin finish.

Anodized

Guidance for specification option:

Metallic finish.

Material

Aluminium

Shape

Rectangle

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Ss_25_10_20_85 Stick curtain walling systemsPrimary

CAWS

H11/110 Curtain walling

Specification data - Stick curtain walling systems

Framing

-

Frame members

Extruded aluminium.

Cladding units

-

Glass units

Insulating glass units.

Single glazed panes.

Glazing system

Dry glazed gasket system.

Guidance for specification option:

Accommodates 10 mm single glazing or 24, 28, or 34 mm insulating glass units.

Panel Type

Guidance for specification option:

A variety of panel thicknesses can be accommodated within the system. Consult with Metal Technology for recommendations and details.

Minimum thickness

Guidance for specification option:

Consult with Metal Technology following choice of finish.

Finish/ Colour

Guidance for specification option:

Consult with Metal Technology for availability of colours and to obtain samples.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

2.69 kg CO₂ eq/m

Guidance for specification option:

Aluminium billet options available 1.9kg CO2e/kg Al and 4.0kg CO2e/kg Al

Manufacturer guidance

Aluminium billet options available 1.9kg CO2e/kg Al and 4.0kg CO2e/kg Al

Third party certifications

Third party certifications

EPD

EPD

Environmental Product Declaration - Curtain Walling

CWCT Certificate

CWCT Certificate

CWCT Membership

ISO 45001 Health and Safety Management

ISO 45001 Health and Safety Management

ISO 45001 : 2018

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001 : 2015

Literature

System 8 Low-rise Curtain Walling

System 8 Low-rise Curtain Walling
