Supertech - Fibre Reinforced Cement Planks

Third party certifications:

BBA Agrément Certificate
Certificate type

Single facet autoclaved cellulose fibre reinforced cement planks.

Jump to:

+44 (0)800 6124662 www.buildingboards.co.uk

Application

Suitable for:

Homes and commercial buildings.
Decorative cladding for residential and commercial buildings.
Steel frame, timber frame, modular/ offsite - masonry.
Low to medium rise masonry and framed buildings (with Z-section metal profiles with 38 mm-deep cavity).
Medium to high masonry or framed buildings (with Allface mounting system with 50–300 mm-deep cavity).

Description

Supertech Weatherboard is a simple to install, fully ventilated rainscreen cladding system which has an appearance similar to that of timber but the durability and strength of cement. Made from refined cellulose fibre cement, Supertech Weatherboard has high levels of impact resistance, excellent weathering properties and outstanding levels of durability. With a minimum life expectancy of 30 years, it is a façade which will withstand the demanding test of time.

Supertech Weatherboard is lightweight, requires low maintenance, can be used in the same way as timber and allows you to create truly stunning façades.

Offering a range of colour painted finishes, Supertech Weatherboard is an attractive alternative to traditional timber boarding and plastic effect PVCu cladding. Supertech Weatherboard can be installed either horizontally in a traditional lapped style (most popular way) or in a vertically lapped style.

Used by architects, national house builders, homeowners and contractors. Supertech Weatherboard is factory finished and provides substantial design opportunities.

Features and benefits:

Made from Specially treated high grade cellulose fibre, Portland cement, refined sand and water.
BBA Accredited.
A1 Fire Classification BS EN 13501-1: 2018.
Quality appearance without the imperfections seen in timber façades.
Resistant to rot, fungus or pest attacks.
Low maintenance and long lasting performance.

Technical characteristics:

Nominal density: 1380 kg/m³.
Bending strength (Modulus of Rupture): 15.85 N/mm².
Modulus of Elasticity (MoE): 6365 N/mm².
Thermal conductivity: 0.30 W/m·K.
Biological resistance: Highly resistant.
Frost resistance: Five star.
Coverage: 0.59 m²
Durability (minimum): 30 years.

General information

Finish	Natural Painted
Color Supertech Weatherboard has a unique colour palette and comes in a standard range of painted colours. Whether your project is rural or urban, it is important that the building blends seamlessly into the landscape. As a result, just in case we don’t have the colour you require in our standard collection, we are able to match Supertech Weatherboard to any RAL, BS or NCS colour. Minimum quantities required.	Beige Black Blue Cream Green Grey Standard. Other Pink Purple Red Silver White Yellow Show more
Material	Cement Refined cellulose fibre cement.
Shape	Rectangle
Size	3660 x 230 mm 3660 x 210 mm 3660 x 190 mm
WarrantyDescription	Ten year On to RCM customer UK.

Uniclass 2015	Pr_25_71_11_31 Fibre-reinforced cement weatherboardsPrimary
CAWS	H20/10 Sheet cladding H20/150 Sheet cladding H20/155 Sheet cladding H21/10 Vertical timber weatherboarding H21/110 Vertical timber weatherboarding H21/111 Horizontal timber weatherboarding H21/15 Horizontal timber weatherboarding

Specification data - Fibre-reinforced cement weatherboards Enhanced data

Standard	To BS EN 13501-1:2018.
Fire rating Supertech Weatherboard with all standard solid colours achieves the highest possible classification to BS EN 13501-1:2018 providing a reaction to fire, Non-Combustible, A1 classification. This classification relates to mounting applications of treated 38 x 47mm timber battens or metal profiles, when fixed with nails or screws (please refer to fixing section for specification of fixings).	A2-s1, d0. In accordance with BS EN 13501-1:2007. Supertech to treated 38 x 47mm timber battens (supplied by others) is A2. An alternative range of A1 non-combustible support frames is available, specified under accessories. Aluminum Z profile is available for low- to medium-rise applications, cavity depth: 38 mm. Allface Helping Hand system; for on medium- to high-rise applications, cavity depth: 50–300 mm.
Edges	Square.
Finished size	3660 x 190 mm.
Face width	190 mm.
Thickness	7.5 mm. Dimensional tolerance: +0.6/-0.2 mm.
Surface texture	Woodgrain textured. Smooth.
Colour Weight: Natural finish: 10.95 kg/m²; painted or stained finish: 11.25 kg/m². UK factory applied colour. Range of colour matching aluminium trims available screws suitable for the installation of the Supertech. Weatherboard are available from RCM and can be supplied self-coloured or colour matched to a chosen colour.	Natural. Standard finish. White. RCM/OP01. Light grey. RCM/OP02. Beige. RCM/OP03. Cream. RCM/OP04. Blue. RCM/OP05. Green. RCM/OP06. Black. RCM/OP07. Graphite grey. RCM/OP08. Dark grey. RCM/OP09. Brown. RCM/OP010. Lilac blue. RCM/OP011. Lavender blue. RCM/OP012. Dark brown. RCM/OP013. Sand yellow. RCM/OP014. Red. RCM/OP015. Fir green. RCM/OP016. Pine. RCM/WS01. Light oak. RCM/WS02. Cedar. RCM/WS03. Dark oak. RCM/WS04. Walnut. RCM/WS05. Ebony. RCM/WS06. Other, RAL. Colour-matching available; insert requirements. Other, BS. Colour-matching available; insert requirements. Other, NCS. Colour-matching available; insert requirements.

Accessories	None. RCM sheathing board. 'Layer 1'; see manufacturer's literature for details. RCM breather membrane. 'Layer 2'; see manufacturer's literature for details. RCM Z-section metal profiles. Alternative to standard timber battens; A1 non-combustible. Cavity depth 38 mm, typically used for low- to medium-rise applications and can be fixed back to both masonry and framed buildings. 'Layer 3'; see manufacturer's literature for details. RCM Allface mounting system. Alternative to standard timber battens; A1 non-combustible. Cavity depth 50–300 mm. Typically used on medium- to high-rise applications where the cavity depth needs to vary and can be fixed back onto either masonry or framed buildings. 'Layer 3'; see manufacturer's literature for details. RCM cavity barrier. 'Layer 4'; see manufacturer's literature for details. RCM EPDM gasket. 'Layer 5'; see manufacturer's literature for details. RCM foil tape. Waterproofing seal. RCM Intusil. Neutral cure sealant for use in gaps and joints. RCM joint seal. Air tightness seal. RCM perforated closures. RCM screws. Nails. Show more
Grain	FG. Fine. SG. Standard.
