SuperLag Quietslab Laminate - Acoustic Laminate Slab Insulation

Name: SuperLag Quietslab Laminate - Acoustic Laminate Slab Insulation
Brand: CMS Danskin Acoustics
SKU: 6hjqqSJ1ryt36Ac3Reaza6

Verified by manufacturer 6 days ago

CMS Danskin Acoustics

Long stranded mineral fibre insulation thermoset with resin into slabs. The inner core of acoustic grade lead or polymeric barrier provides a high degree of resistance to the passage of sound.

Jump to:

Request BIM

+44 (0)1925 577711 Website

Application

Suitable for a wide range of building and industrial applications. The highly versatile material with an extensive listing of applications such as acoustic ceilings, partition panels, walls, floors, roofs, ductwork and industrial enclosures. Extended applications include thermal insulation for boilers, heat exchangers, plant, tanks and pipes. SuperLag Quietslab Laminate can be flat or curved to suit requirements.

Description

SuperLag Quietslab Laminate is manufactured from long stranded mineral fibres that are thermo-set with resin into slabs. The inner core of acoustic grade lead or polymeric barrier provides a high degree of resistance to the passage of sound.

Features and benefits:

Excellent thermal and acoustic insulation.
Chemically inert.
Cost effective and easy to install.
Combined thermal and acoustic performance.
Available in a wide range of coverings and facings.
Can be produced with a choice mass barrier materials: polymeric mass barrier or lead sheeting.

General information

Color	Brown
Finish	Foil Glass tissue Film Other
Material	Mineral fibre Polymeric Lead
Shape	Rectangle
Length	1200 mm Bespoke
Width	600 mm Bespoke
Height	25 mm 50 mm 60 mm 75 mm 100 mm Bespoke Show more Manufacturer guidance Thickness.

Uniclass	Pr_25_57_06_71 Resilient layer insulationPrimary
CAWS	U90/490 Site-applied insulation to ductwork K40/285 Insulation K40/55 Insulation

Specification data - Resilient layer insulation

Classification data
Material	Mineral fibre insulation with polymeric mass barrier. Guidance for specification option: Polymeric mass barrier available as 5, 7.5 and 10 kg/m². Mineral fibre insulation with lead sheeting. Guidance for specification option: Lead sheeting available as 5, 10 and 15 kg/m².
Density	60 kg/m³.
Thickness	25 mm. 50 mm. 60 mm. 75 mm. 100 mm. Other. Guidance for specification option: Non-standard thicknesses are available upon request; consult manufacturer for more details and insert requirements.
Fire performance	To EN 13501-1, B-s1,d0. Guidance for specification option: For unfaced c/w polymeric barrier (combination with lead core untested). Certificate available on request.
Sound insulation rating	- Manufacturer guidance Certificates available on request. Acoustic insulation performance varies dependant on material and thickness specified; consult manufacturer for more details and insert requirements.
Facing	Unfaced. Class 0 foil facing. Glass tissue scrim 60 gm/m². Guidance for specification option: Black and white. Glass cloth 200 gm/m². Guidance for specification option: Black and white. Melinex polyester film.
Size (length x width)	1200 x 600 mm. Other. Guidance for specification option: Non-standard slab sizes available upon request; consult manufacturer for more details and insert requirements.
Compressive strength (minimum) at 10% compression	6.7 N/m².
Technical characteristics, other	Stress to reach elastic limit: 6.1 kN/m². Displacement at 5 kN/m²: 7.8%.
ThermalConductivity	Mineral fibre: 0.034 W/mK.
