Superglass Timber And Rafter Roll 32 - Timber frame insulation

Verified by manufacturer 1 day ago

Timber And Rafter Roll 32 - 90 mm

Superglass Insulation Ltd Variant:
Third party certifications:
  • ISO 14001 Environmental Management Systems

    Certificate type

  • EPD

    EPD

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • UK Conformity Assessed (UKCA)

    UK Conformity Assessed (UKCA)

    Certificate type

  • CE Marking

    Certificate type

  • Made in Britain

    Made in Britain

    Certificate type

  • BS EN 13501-1

    BS EN 13501-1

    Certificate type

Superglass Timber & Rafter Roll 32 is a lightweight, non-combustible glass mineral wool insulation roll use in timber frame walls, roofs & floors.

Jump to:
+44 (0)808 1645 134 Website

Application

Superglass Timber & Rafter Roll 32 is designed to provide thermal insulation for external timber frame walls, warm pitched roofs, and suspended timber floors.

Description

Superglass Timber & Rafter Roll 32 is a non-combustible glass mineral wool insulation roll. The flexible roll is cut at 2x570mm widths to allow friction fitting between common stud/rafter spacings minimising gaps at joints and reducing on-site cutting.


Thermal Conductivity:

Declared thermal conductivity (lambda (λ) value) of 0.032W/mK.


Fire Classification:

Deemed non-combustible with a fire classification of Euroclass A1 (the highest possible rating) when tested to BS EN 13501-1 Reaction to Fire.


Vapour Resistivity

The product has a nominal vapour resistivity of 5 MN·s/g·m.


Environmental credentials.

  • Manufactured in accordance with ISO 14001 - Environmental Management Systems (EMS). Certificate number: EMS 646508.
  • Contains no ozone-depleting substances or greenhouse gases. For more information, please refer to the Environmental Product Declaration (EPD).
  • Made from up to 84% recycled glass.
  • Generic BRE Green Guide Rating of A+.


Standards and Approvals.

  • BS EN 13162:2012(+A1:2015) Thermal insulation products for buildings - Factory made mineral wool (MW) products.
  • BS EN 13172: 2012 Thermal insulation products – Evaluation of conformity.
  • BS EN ISO 9001 - Quality Management Systems (QMS). Certificate number: FM 02264.


Certification:

  • UKCA certified to BS EN 13162:2012+A1:2015. Certificate number: 0086 CPR 469699.
  • CE marked to BS EN 13162:2012+A1:2015. Certificate number: 0751-CPR-399.0-01.


General information

Color

Yellow

Material

Glass mineral wool

Mineral wool

Mineral fibre

Shape

Rectangle

Length

2800 mm

3900 mm

Width

570 mm

Height

90 mm

140 mm

Uniclass

Pr_25_57_06_53 Mineral wool insulationPrimary

CAWS

B15/120 Timber-framed

K11/115 Battened plywood floating floor

K11/125 Battened particleboard floating floor

K11/135 Battened oriented strand board floating floor

K11/145 Battened cement-bonded particleboard floating floor

K11/20 Battened particleboard floating floor

K11/215 Plywood floating floor

K11/225 Particleboard floating floor

K11/235 Oriented strand board floating floor

K11/245 Cement bonded particleboard floating floor

K11/25 Particleboard floating floor

K11/275 Acoustic separating floor system

K13/160 Proprietary

K20/150 Battened timber board floating floor

K20/20 Battened timber board floating floor

K21/10 Wood laminate flooring

K21/111 Wood floating floor

K21/115 Wood laminate flooring

K21/120 Battened wood flooring

K21/130 Battened wood floating floor

K21/140 Battened wood laminate flooring

K21/145 Composite laminate flooring

K21/20 Composite laminated flooring

P10/140 Insulation fitted between rafters

P10/15 Insulation fitted between rafters

P10/190 Insulation fitted between studs

P10/240 Insulation fitted between floor joists

P10/40 Insulation fitted betweenor to the face ofstuds

P10/45 Insulation laid between floor joists

P10/50 Insulation supported between joists

Product range

Timber Floor Insulation
Timber Frame Wall Insulation
Glass Mineral Wool Insulation
Timber Frame Roof Insulation

Specification data - Mineral wool insulation

Standard

To BS EN 13162.

Manufactured in accordance with BS EN 13162:2012(+A1:2015) Thermal insulation products for buildings factory made mineral wool (MW) products. BS EN 13172:2012 Thermal insulation products evaluation of conformity. BS EN ISO 9001:2015 – Quality Management Systems (QMS).

Form

Glass mineral wool insulation roll.

Thickness (minimum)

90 mm.

Width (nominal)

2 x 570 mm.

Supplied in two width of 570 mm.

Thermal conductivity (maximum)

0.032 W/m·K.

Fire performance

Reaction to fire classification of A1, as defined in BS EN 13501-1.

All Superglass products are deemed non-combustible and have a fire classification of A1 when tested to BS EN 13501-1 reaction to fire.

Recycled content

Up to 84%.

Manufactured from up to 84% recycled glass which would otherwise go to landfill.

R-Value

2.80 m²K/W

Length

3900 mm.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

Guidance:

Please see product EPD.

1.35 kg CO₂ eq/kg

Recycled content

84 %

Manufactured from up to 84% recycled glass which would otherwise go to landfill.

EPD

BIM objects

Platform Compatible Version
Revit
-

1

Third party certifications

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

Environmental Management System ISO 14001: 2015

EPD

EPD

Environmental Product Declaration (EPD) – Cured Glass Mineral Wool Insulation

ISO 9001 Quality Management

ISO 9001 Quality Management

Quality Management System ISO 9001:2015

UK Conformity Assessed (UKCA)

UK Conformity Assessed (UKCA)

UKCA Certificate - Cured Glass Mineral Wool Insulation

CE Marking

CE Marking

CE Certificate - Blown Glass Mineral Wool Insulation

Made in Britain

Made in Britain

Made in Britain

BS EN 13501-1

BS EN 13501-1

Euroclass A1 Reaction to Fire Classification

Literature

Superglass Timber & Rafter Roll 32 - Datasheet

Superglass Timber & Rafter Roll 32 - Datasheet

Insulation Solutions Guide

Insulation Solutions Guide
