NBS Source
SUNTUF®

Application

  • Agricultural greenhouses.
  • Architectural roofing and skylights.
  • Industrial rooflights.
  • Light roofing and awnings.
  • Residential roofing: Pergolas, canopies, etc.

Description

SUNTUF is a corrugated polycarbonate sheet for architectural, industrial, agricultural, and DIY applications, including skylights/ rooflights, sidelights, and complete corrugated polycarbonate roofing and cladding solutions. Weighing half the weight of glass, SUNTUF corrugated sheets also offer multiple advantages over traditional alternatives: up to 20 times greater impact resistance, the highest light transmission rates, the lowest yellowing index, the highest load rating, and the highest resistance to wind uplift. These properties confirmed in accredited laboratory testing and in installations around the world since 1984, make SUNTUF corrugated polycarbonate roofing an optimal solution.


SUNTUF polycarbonate skylights/rooflights and corrugated polycarbonate sheets are available in hundreds of profiles and match all standard metal profiles. MetalMatch™ technology gives an almost unlimited ability to customize new solutions, and design a tailor-made corrugated profile for structures.


SUJNTUF’s full line of installation accessories and instructions enables weather-tight fit and long-term performance.


Features and benefits:

  • Impact resistant and virtually unbreakable.
  • Transparent: up to 90% light transmission.
  • Weather and UV resistant.
  • Wide service temperature range.
  • Blocks 99.9% of harmful UV radiation.
  • Lightweight – less than half the weight of glass.
  • Good fire rating.
  • Easy to work with and install.
  • Wide service temperature range.
  • Heat deflection temperature: 130°C.
  • Impact strength @ 3 mm thickness: 158 J.
  • Flexural modulus (1.3 mm/minimum): 1890 MPa.

General information

Color

Blue

Brown

Clear

Cream

Green

Show more

Finish

Embossed

Hair-Cell

Smooth

Standard.

Material

Polycarbonate

WarrantyDescription

Ten year

Limited warranty.

Uniclass 2015

Pr_25_71_63_65 Polycarbonate profiled sheetsPrimary

CAWS

B91/330 Canopy

B91/335 Covered walkway

B91/345 Greenhouse/ Glasshouse

H30/160 Profiled plastic sheet rooflights or wall lights

H30/30 Air and vapour control membrane

H31/160 Profiled plastics sheet

H31/30 Profiled plastics sheet

H32/120 Plastics

Specification data - Polycarbonate profiled sheets Enhanced data

Performance requirements

-

Light transmission

Clear: Transmits up to 90% natural daylight, resulting in high lighting within the structure.

Opaque: These colours transmit very little to no light.

Transparent: Low haze colours offering high clarity. Breeze and Smart colours offer advanced heat blocking that reduces heat build-up while allowing a clear view through the sheet.

Translucent: White Opal transmits 24–45% visible light with high light dispersion, produces mild and even lighting within the structure. Diffuser transmits 85% visible light with complete light dispersion, produces diffused and consistent lighting within the structure.

90%.

Clear sheet.

85%.

Diffuser.

25–45%.

White Opal.

Thickness (nominal)

Insert requirement, dependent on profile selection.

-

Profile

Available in over 200 profiles and can be matched into any existing or custom tailored corrugation profile on demand using Palram's proprietary profile matching technology.

Length

As drawing.

Insert requirements.

Cover width

As drawing.

Insert requirements.

Finish as delivered

Embossed.

Hair-Cell.

Smooth.

As standard.

Colour

Custom colors are available upon request and subject to a minimum order.

Clear.

Transparent.

Solar Grey.

Transparent.

Bronze.

Transparent.

Sky Blue.

Transparent.

Transparent Green.

Transparent.

Smart Grey.

Transparent.

White Opal.

Translucent.

White Diffuser.

Translucent.

Solar Control.

Translucent.

Solar Ice.

Translucent.

Mist Green.

Translucent.

Smooth Cream.

Translucent.

White.

Opaque.

Green.

Opaque.

Blue.

Opaque.

Red Brick.

Opaque.

Product Reference

SUNTUF®.

With integrated UV protective layer on one side.

SUNTUF® Breeze.

Part of the SolarSmart™ family. Breeze offers unsurpassed performance providing 'cool light' with the highest clarity and near infer-red selectivity.

SUNTUF® Embossed.

Embossed or Hair-Cell finish on one side.

SUNTUF® Smart.

SolarSmart™ Advanced heat blocking combined with low haze.

SUNTUF® Solar Control.

SolarSmart™ Transmits selected percentages of daylight (20, 35 or 50%) while reflecting and absorbing some of the heat-generating Infra-Red radiation.

Show more

Density

1.2 g/cm³.

Flexural strength

93 MPa.

1.3 mm/min.

Modulus of elasticity

2300 MPa.

1.3 mm/min.

Service temperature range

-50 to +100°C.

TensileStrength

62 MPa at yield, 65 MPa at break.

ThermalConductivity

0.21 W/mK.

Environmental information

Country of material origin

EU.

Country of product manufacture

United Kingdom

Recyclability

Polycarbonate sheets can be recycled at end of life.

Recycled content

%

10-40 %.

Literature

Suntuf - Corrugated Polycarbonate Sheet

Suntuf - Corrugated Polycarbonate Sheet

Third party certifications

  • ISO: 9001 2008
  • ISO: 14001:2004
  • BSEN: 13501 B-s1-d0
  • REACH compliant
  • RoHS compliant
