SUNLITE®

Third party certifications:

QA Certificate
Certificate type

Multiwall structured, flat polycarbonate sheet.

Jump to:

Application

Architectural roofing and glazing.

Conservatory roofing.

Covered walkways.

Decorative partitions.

Greenhouse and garden centre roofing.

Illuminated signage and displays.

Skylights and sidelights.

Description

SUNLITE® has a cellular polycarbonate structure that yields a lightweight sheet with high impact strength and superior thermal insulation. High light transmission makes SUNLITE® ideal for varied roofing, wall cladding and glazing applications. The SUNLITE® product range includes heat-blocking SolarSmart™ sheets that reduce heat build-up and anti-condensation treatment for greenhouses and garden centres. With 99.9% UV blocking properties it is the ideal solution for providing UV shading for public areas.

Features/ Benefits:

Blocks virtually all UV radiation.

Easy to handle and install.

Excellent structural durability.

Extremely Lightweight yet impact resistant.

High fire ratings.

High light transmission.

High thermal insulation.

Weather and UV resistant.

Applications:

Architectural roofing and glazing.

Conservatory roofing.

Covered walkways.

Decorative partitions.

Greenhouse and garden centre roofing.

Illuminated signage and displays.

Skylights and sidelights.

General information

Size	As drawing
Uniclass 2015	Pr_25_71_63_18 Composite and recycled plastics sheetsPrimary

Specification data - Composite and recycled plastics sheets

Product Reference	SUNLITE® Standard sheet with UV protection on one side. SUNLITE® Breeze Part of the SolarSmart™ family. Breeze offers unsurpassed performance providing the highest clarity and near infer-red selectivity. SUNLITE® CL SolarSmart™ heat blocking sheet for architectural applications. SUNLITE® ML Multi-layered colour combinations for special designs. SUNLITE® Plus With anti-condensation, for greenhouses. SUNLITE® SLT SolarSmart™ heat blocking and anti-condensation sheet for garden centres. SUNLITE® Smart SolarSmart™ transparent sheet with advanced heat-blocking properties. Incorporates near infer-red selectivity providing 'cool light'. SUNLITE® Solar Control SolarSmart™ metallic reflective heat blocking sheet. SUNLITE® UV2 With integrated UV protective layer on both sides.
Size	As drawing
Type	Twin Wall Available in 4, 4.5, 6, 8 and 10 mm thicknesses. Triple Wall Available in 8, 10 and 16 mm thicknesses. V-Structure Available in 20, 25, 32, 35 and 40 mm thicknesses. X-Lite Available in 16, 25, 32, 35 and 40 mm thicknesses.
Thickness	Insert requirement.
Width	Insert requirement, dependent on type and thickness, consult manufacturer's literature for more information.
Colour	Not applicable For SUNLITE® CL and SLT. Blue Standard colours. Bluish Breeze Solar Smart™. Bronze Standard colours. Clear Standard colours. Green Standard colours. White Diffuser Standard colours. White Opal Standard colours. Bronze/Opal Multilayered colours for SUNLITE® ML. Solar Guard (Solar Control/Opal) Multilayered colours for SUNLITE® ML. Smart Green SolarSmart™. Solar Control SolarSmart™. Solar Ice SolarSmart™.
Connecting profiles	Insert requirements; consult manufacturer's literature for more information.

Standard product features

Technical properties:
Density: 1.2 g/cm³.
Heat deflection temperature: 135°C.
Coefficient of linear thermal expansion: 6.5 x 10E-5 mm/°C.
Practical thermal expansion/contraction: 3 mm/m.
Impact strength: 40–400 J.
Elongation at break (10 mm/min): >90%.
Fire resistance (to BS EN 13501): B, s1, d0.
Service temperature: -50 to +100°C long term, -50 to +120 short term.
Tensile strength at yield (10 mm/min): 62 MPa.

Product Options

Colour:
Availability is dependent on type and thickness, consult manufacturer's literature for more information.

Literature

Sunlite Plus - Multiwall Polycarbonate Sheet with Anti-Condensation

Sunlite - Multiwall Polycarbonate Sheet

Third party certifications

ISO: 9001 2008
ISO: 14001:2004
BS EN: 13501 B-s1-d0 - dependent on thickness
REACH compliant
RoHS compliant
