Application

Suitable for parks, nature reserves, heritage sites and schools (including lower school).

Description

Softwood timber bench that can be used independently or as a coordinated suite of products (with seats, tables and picnic tables also available separately).

The softwood construction makes for an economical alternative to hardwood seating and table ranges, with pressure treatment providing good medium-term durability. The range is characterized by heavy-duty timber sections with bolted connections to give a tough, almost industrial aesthetic.

All timber sections are ‘regularized’ with planed faces and eased edges, with cross-cuts also softened to eliminate sharp edges and reduce the risk of splintering. Softwood can be supplied in a ‘natural’ pressure treated finish which can add a slight green tinge to the pale colouration of the timber, or can be treated with a supplementary saturating oil in a variety of tinted colours.


Features and benefits:

  • Products are supplied part-assembled and flat packed for on-site assembly.
  • All product fixings are provided, with the exception of ground anchors and the adhesive.
  • Products can be supplied fully assembled (at additional cost).


Above ground installation:

  • Each unit is pre-drilled with four 15 mm holes for M10 or M12 fixings (not supplied).
  • An optional fixing kit comprising two M10 x 330 mm long threaded studs with nuts and washers is available, supplied for attachment to the baseplate and fixing into a suitable new or existing foundation.
  • Ideal for installation in soft ground.


In-ground installation:

  • Posts roots can be set into concrete with the base plates helping to prevent any lift out.
  • Alternatively, posts can be bolted to a below-ground concrete pad with two M12 ground anchors (not supplied), or set into concrete using a fixing kit (as above).

General information

Color

Brown

Guidance for specification option:

Timber.

Clear

Guidance for specification option:

Oiled finish.

Grey

Guidance for specification option:

Steel baseplates.

Finish

Galvanized

Material

Timber

Steel

Shape

Rectangle

Length

1500 mm

1800 mm

2100 mm

2400 mm

Width

225 mm

470 mm

175 mm

356 mm

Height

455 mm

355 mm

Warranty description

One year

Uniclass

Pr_40_30_29_84 Street and site benchesPrimary

CAWS

Q50/220 Benches

Q50/30 Street furniture

Product range

Seating

Specification data - Street and site benches

Length

1.5 m.

Base

Bolt-down via baseplates.

Guidance for specification option:

Above ground installation.

Bolt-down via baseplates onto below ground (with extended depth legs).

Guidance for specification option:

In-ground installation.

Concrete pad with fixing kit.

Guidance for specification option:

Above ground installation.

Freestanding (supplied with feet).

Into concrete pad (with extended depth legs).

Guidance for specification option:

In-ground installation.

Material

Seating: Treated softwood, Baseplates: Galvanized steel.

Finish as delivered

Oiled finish, cedar.

Guidance for specification option:

Optional, subject to minimum quantity orders.

Oiled finish, clear.

Guidance for specification option:

Optional, subject to minimum quantity orders.

Oiled finish, light oak.

Guidance for specification option:

Optional, subject to minimum quantity orders.

Oiled finish, medium oak.

Guidance for specification option:

Standard.

Oiled finish, redwood.

Guidance for specification option:

Optional, subject to minimum quantity orders.

Oiled finish, rustic oak.

Guidance for specification option:

Optional, subject to minimum quantity orders.

Oiled finish, teak.

Guidance for specification option:

Optional, subject to minimum quantity orders.

Colours

Brown and grey.

Armrests

Not required.

Guidance for specification option:

Junior bench or full size single slat bench.

One mid and two end armrests.

One mid armrest.

Three mid and two end armrests.

Guidance for specification option:

2400 mm long unit.

Three mid armrests.

Guidance for specification option:

2400 mm long unit.

Show more

Manufacturer guidance

  • Armrests are a useful aid for the less-able-bodied in particular, helping them to lower themselves onto a seat and also alight from it. Armrests can also deter rough sleeping if placed appropriately. All full-size Stark seating products, with the exception of the Single Slat Bench, are available with armrests.
  • The simple block forms, which have an overhang that can be firmly gripped, are pre-fitted at any of the positions shown on the illustrations below, which are designed to maintain comfortable seating widths. If the need for armrests is only identified after the product has been installed, they can be easily retro-fitted.
  • Consult technical literature for size information; varies depending on the configuration.


Form

Full size, single slat.

Size:

225 x 455 mm.

Guidance for specification option:

Full size single slat.

Type:

Part-assembled.

Fully-assembled.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Literature

Contemporary Seating & Table Ranges

Contemporary Seating & Table Ranges
