ST40 - Glazed Sliding Door
Verified by manufacturer 3 months ago
EPD
Certificate type
Single glazed aluminium framed acoustic sliding door with aluminium head track, stainless steel floor rail and glazed partition.
Application
Suitable for integration into Savile Row Projects partition systems, including:
- System 3500
- System 3400
- System 2000
Description
Single glazed aluminium framed sliding door with aluminium head track, stainless steel floor rail and glazed partition.
Feature and benefits:
- Acoustic sliding door dlivering Rw 37 dB acoustic insulation
- Robust sliding mechanism incorporates a full width acoustic seal. Being a dual axis sliding door, the ST40 compresses the perimeter seal relying on the door motion rather than a top hung mechanism. This gives consistent acoustic performance over time with no readjustment needed.
- Mitred frame and leaf profiles have a high quality aesthetic.
- Available with a range of ironmongery options and accessories.
- Can be used in conjunction with all Strahle partitions.
General information
Color | Clear Guidance for specification option: Glass. Black Bronze Other Guidance for specification option: Frame. Anodized or polyester powder-coated to any RAL colour. |
Finish | Anodized Powder-coated Unfinished |
Material | Glass Aluminium Stainless steel |
Shape | Rectangle |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L20/55 Doorsets L20/520 Sliding doors |
Specification data - Sliding door and partition sets
Classification data | |
Performance | Internal. |
Arrangement | Single-leaf top-hung. |
Track system | Top hung aluminium head track with stainless steel floor rail. |
Door leaves | |
Construction | Door: 12.8 mm acoustic laminated glass. Partition: 16.8 mm acoustic laminated glass. |
Finish and colour | Clear. |
Operation | Manual. |
Hardware | Door stop. Manufacturer guidanceRefer to 'handle type' and 'lock type' bellow and insert requirements. Hardware available brushed stainless steel as standard. Black and bronze options also available, insert requirements. |
Accessories | None. Tech panel. Guidance for specification option: Consult manufacturer for details and insert requirements. |
Dimensions | Manufacturer guidanceUp to: 3000 x 1100 mm (height x width). Consult manufacturer and insert requirements. |
Weighted sound reduction index, Rw | Door: 37 dB. Partition: 40 dB. |
Perimeter seals | Drop down acoustic seal. |
Frame | Aluminium. |
Frame finish | Exposed metal. Anodized. Guidance for specification option:
Insert requirements. Polyester powder-coated, RAL. Guidance for specification option: 25% gloss. Powder-coated to any RAL colour. Insert requirements. |
Handle type | SRP offset pull handle - concealed closer. Lever handle - manual close. Lever handle - concealed closer. Other. Guidance for specification option: Client specified alternative, consult manufacturer and insert requirements. Manufacturer guidance
Consult manufacturer and insert requirements. |
Lock type | Euro cylinder. Morticed EM lock. Surface mounted EM lock. Blank escutcheon. Manufacturer guidanceAvailable brushed stainless steel as standard. Black and bronze options also available. Insert requirements. |
Gaskets | Black. Grey. |
Sustainability data
Material | Glass Aluminium Stainless steel |
