SPW600e Casement Window System [Curtain Wall Placement]

Name: SPW600e Casement Window System [Curtain Wall Placement]
Brand: dVSDoRHE7zaprhEbgnigyf
SKU: gws8FLQEPTYYAEhuPoDE7t

Senior Architectural Systems Ltd

A three chamber aluminium, 75 mm polyamide casement window system that achieves impressive thermal performance.

Jump to:

+44 (0)1709 772600 www.seniorarchitectural.co.uk

Description

Three chamber 75 mm polyamide window system which achieved good thermal performance.

An enhancement to the SPW 600 Suite of windows which introduces a polystyrene strip in the thermal break cavity alongside a backer rod situated around the insulated glazed unit (IGU) ensure the window exceeds the rigorous standards set in the Building Regulation (E&W) Approved Document L.

Flexibility:

Available in casement, tilt/turn and top swing reversible windows, suitable for educational, commercial and retail applications, transport terminals, health service buildings etc.

Construction:

Constructed with mitred and mechanically crimped or joined corners, with support chevrons and cleats to ensure accurate alignment. Integral transoms and mullions are fixed into the outer frames with screws or brackets. Joints are sealed against water ingress during assembly.

Opening lights are inserted directly into the outer frames on butt hinges or friction stays.

Vent frames can be fixed directly into the framing modules. Individual modules can be fully assembled and then transported to site.

The windows incorporate an integral polyamide thermal break.

General information

Size	As drawing As schedule
Finish	Anodized Insert colour requirements, 25 microns (minimum), satin or polished finish available. Mill finish Polyester powder coated Insert colour requirements, 40 microns standard and 60 microns available for marine environments.
Features	Includes a polystyrene strip in the thermal break cavity alongside a backer rod situated around the insulated glazed unit
Material	Aluminium and glass

Uniclass 2015	Pr_30_59_98_02 Aluminium window unitsPrimary
CAWS	L10/25 Aluminium windows L10/330 Aluminium windows

Specification data - Aluminium window units

Product Reference	SPW 600e
Size	As drawing As schedule
Type	Overswing Side hung Tilt/turn Top hung
Finish	Anodized Insert colour requirements, 25 microns (minimum), satin or polished finish available. Mill finish Polyester powder coated Insert colour requirements, 40 microns standard and 60 microns available for marine environments.
Glazing	-
Type	Insulated glass unit – Insert thickness required, 26–56 mm available
Glazing method	Inside glazed As standard. Outside glazed
Ironmongery/ Accessories	Manufacturer's standard

Standard product features

Size:

- Overswing open out:

Maximum width: 1500 mm.

Maximum height: 1600 mm.

- Side-hung:

Maximum width: 900 mm.

Maximum height: 1500 mm.

- Tilt-turn:

(Minimum)–Maximum width: (450)–1500 mm.

(Minimum)–Maximum height: (500)–1500 mm (heavy duty, 2200 mm).

- Top-hung:

Maximum width: 1500 mm.

Maximum height: 1500 mm.

Material:

Extruded aluminium: Aluminium alloy 6063.T6 to BS EN 755-9.

Polyamide thermal barriers are manufactured in accordance with PA66 GF25.

Gaskets are manufactured in accordance with BS 3734.

U-Value:

Separate figures are available for Thermal U-values depending on type of window configuration, frame and glazing material, consult manufacturer for details.
