Sport and activity solid hardwood floors with floating clip system

Verified by manufacturer 2 months ago

Junckers Ltd Third party certifications:
  • EPD

    EPD

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

Multi purpose solid hardwood overlay sprung sports floor system.

Jump to:
BOS
+44 (0)1376 534700 Website

Application

  • Suitable for all types of sport.
  • Multi-functional sports halls.
  • From small leisure centres to large arenas.
  • Refurbishment.
  • Suitable for underfloor heating.

Description

A 22 mm thick multipurpose sports floor for use where badminton, hockey, volleyball, netball, basketball and five a side football are played. The system features 129 mm wide x 3700 mm long boards, manufactured from two rows of 623 mm long, graded, press dried beech staves, dovetail jointed together. The boards have precision machined tongued and grooved edges, which facilitate assembly and ensure square, secure joints. A moisture balancer is applied to the underside.


Boards are fitted together, in stagger pattern, using Junckers Steel Clips that fit into grooves machined in the back of the boards. The floor floats over a 10 mm performance foam underlay for maximum resilience. Designed for heavy wear and durability, the flooring can be laid directly over an existing flat and level subfloor or over an existing sound but substandard playing surface. Available factory finished and, if necessary, can be refinished using suitable cleaning agents and lacquers. Renovation by in-situ precision sanding and refinishing is also possible.


Features and benefits:

  • Available with SylvaSport and Sylvatech floorboards.
  • Available in Champion, Premium and Club grades.
  • Badminton World Federation and FIBA accredited.
  • Area-elastic according to EN 14904 class A3.
  • FSC and PEFC certified.
  • Danish Indoor Climate certified (lacquered finishes).
  • EN 15804 EPD.

General information

Color

Brown

Finish

Matt

Guidance for specification option:

Ultramatt lacquered or silkmatt lacquered.

Material

Wood

Length

3700 mm

Width

129 mm

Height

22 mm

Manufacturer guidance

Thickness.

Warranty description

25 year

Uniclass

Ss_30_20_95_95 Wood floating floor systemsPrimary

CAWS

K21/111 Wood floating floor

Specification data - Wood floating floor systems

System performance

To EN 14904, class A3.

Vapour control layer

Junckers SylvaThene.

Underlay

10 mm Junckers SportsFoam.

Flooring

-

Board type

Beech SylvaSport.

SylvaTech Plus.

Maple.

Ash.

Manufacturer guidance

22 mm 2-strip solid hardwood. Width: 129.0 mm (±0.2 mm). Length: 3700 mm (±1.0 mm).

Perimeter flanking seal

Junckers Expansion strip.

Guidance for specification option:

12 x 12 x 1000 mm.

System accessories

None.

Nosing.

Skirting.

Stair nosing.

Appearance

Champion.

Guidance for specification option:

Where a uniformly coloured floor is needed in dedicated sports halls.

Premium.

Guidance for specification option:

For use where the main activity is competitive sport.

Not available for Maple.

Club.

Guidance for specification option:

For general use.

Finish as delivered

UV light cured lacquer plus Junckers polyurethane Isolacquer - Ultra matt.

UV light cured lacquer plus Junckers polyurethane Isolacquer - Silk matt.

Untreated.

Guidance for specification option:

Not available for Maple.

Additional site applied

None.

1 coat Junckers High Performance sports seal.

Guidance for specification option:

Typically applied on completion of flooring, e.g. to protect line markings.

Court line markings, in Junckers HP SportsLine paint.

Method of fixing

Clip System.

Guidance for specification option:

17 No. clips per m².

Clip size is determined on the basis of expected maximum relative humidity in the building during the year; contact manufacturer for recommendations.

Third-party certification

FSC, PEFC and Danish Indoor Climate certified, EN 15804 EPD.

Sustainability data

Contains Red List materials

No

Country of material origin

-

Manufacturer guidance

Europe.

Country of product manufacture

Denmark

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

See EPD.

Recyclability

Recyclable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
