Speed Bumps - Traffic Safety Management
Verified by manufacturer 4 months ago
Speed Bumps: Engineered for traffic calming, our solutions enhance road safety by effectively reducing vehicle speed and promoting controlled driving.
Application
This traffic safety management feature can be used to calm traffic speeds. Speed Bumps can be used for:
- Traffic calming applications on concrete or tarmac.
- Suitable for reducing speed within car parks, parking lots, slow traffic roads, and warehouse loading bays.
Description
Speed Bump designed to calm traffic.
Features and benefits:
- Heights: 50 mm for domestic/LGV and 75 mm for HGV traffic.
- Vibrant yellow five-bar checker design.
- Night time visibility with silver reflectors.
- Tarmac/concrete-compatible fixings.
- End sections: Two M12 fixings, 250 mm wide pedestrian-friendly domed ends.
- Mid sections: 500 mm wide x 420 mm deep (50 mm)/480 mm deep (75 mm), 4 M12 fixings.
General information
Color | Black Yellow |
Finish | Reflective |
Material | PVC-U |
Shape | Crescent Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | Q10/315 Traffic calming humps |
Specification data - Speed restriction ramps
Material | PVC-U. |
Dimensions | |
Width | 500 mm.250 mm. |
Height above carriageway | 50 mm.75 mm. |
Overall length | Manufacturer guidanceBespoke. Consult the manufacturer for details and insert requirements. |
Colour | Black and yellow. |
Accessories | Retro-reflective tape. |
Fixing: | M12 fixings. |
Depth: | 420 mm. 480 mm. |
Product Reference | Speed Bump Mid Speed Bump Dome End |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | 100% |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
Literature
Speed Bumps (Domestic Vehicles) - Brandsafe Spec Sheet
Speed Bumps (Commercial Vehicles) - Brandsafe Spec Sheet
