Application

Suitable for:

  • Floors and walls.
  • Use with underfloor heating.
  • Floating floor - consult manufacturer for underlay options (not suitable for Delamere in widths of 260 or 300 mm).
  • Joists - maximum 400 mm centres (not Winterfold).

Description

Engineered wood flooring, designed to be laid in a plank format.

Features and benefits:

  • Part of the SPECIALIST WOODS collection; consult manufacturer's literature for other formats.
  • EU Timber Regulation (EUTR) compliant.
  • Can be fully bonded to subfloor (with Ted Todd MS Flex high strength adhesive).

Applications:

Suitable for:

  • Floors and walls.
  • Use with underfloor heating.
  • Floating floor - consult manufacturer for underlay options (not suitable for Delamere in widths of 260 or 300 mm).
  • Joists - maximum 400 mm centres (not Winterfold).

- Can be installed over:

  • Concrete (dry, flat; not Winterfold).
  • Plywood.
  • Screed (dry, flat; manufacturer recommends Primerfast moisture barrier).

Related products:

A range of complementary products is available for some planks, including L-sections, T-sections, reducers, scotia, skirting and architraves. Consult manufacturer for details.

Guarantee:

  • Birnham/ Blackmuir/ Darwin/ Delamere/ Rockingham: 25-year product warranty.
  • Winterfold: 20-year product warranty.

General information
Specification data - Wood laminate strips and boards
Product Reference

SPECIALIST WOODS Collection - Plank

Type

Birnham

Blackmuir, matt hardwax oil finish

Blackmuir, unfinished

Site preparation required.

Darwin

Delamere

Rockingham, matt hardwax oil finish

Rockingham, unfinished

Site preparation required.

Winterfold

Width

135 mm

Birnham and Darwin only.

180 mm

Delamere only.

190 mm

Blackmuir, Rockingham or Winterfold only.

220 mm

Blackmuir, Delamere or Rockingham only.

260 mm

Delamere only.

300 mm

Delamere only.

Standard product features

Technical characteristics:

  • Construction: Two ply engineered, 100% hardwood.
  • Profile: Tongue and grooved to all sides.
  • Edge detail: Micro bevelled.
  • Surface texture: Smooth.
  • Moisture content: 8–12% fair and average.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Fire rating to EN 13501-1 (flooring): D fl - s1.
  • Emissions to EN 14342: E1.
  • Humidity requirements: Between 40% and 60% relative humidity.
  • Formaldehyde emission: E1.
  • Batch variation: Not advised to mix batches in one floor area.

Product Options

Type:

- Birnham:

  • Wood species: Tajibo.
  • Grade: Exotic wood.
  • Wear layer: 6 mm hardwood (nominal).
  • Finish: Satin lacquer.
  • Certification: FSC 100%.
  • Tolerance: ±0.50 mm/ 95% in tolerance.
  • Janka hardness rating: 1500 lbf (6670 N).
  • Thermal conductivity: 0.10 m²K/W (1.0 Tog).
  • Tonal variation: Medium natural.
  • Thickness: 19 mm.
  • Length: Random, up to 1.83 m.
  • Tone: Dark.

- Blackmuir (all):

  • Wood species: American black walnut.
  • Grade: Nature.
  • Wear layer: 6 mm hardwood (nominal).
  • Finish: Matt hardwax oil or unfinished.
  • Tolerance: ±0.50 mm/ 95% in tolerance.
  • Janka hardness rating: 1010 lbf (4500 N).
  • Thermal conductivity: 0.10 m²K/W (1.0 Tog).
  • Tonal variation: Medium natural.
  • Thickness: 20 mm.
  • Length: Random, up to 1.83 m.
  • Tone: Dark.

- Darwin:

  • Wood species: Morado.
  • Grade: Exotic wood.
  • Wear layer: 6 mm hardwood (nominal).
  • Finish: Satin lacquer.
  • Certification: FSC 100%.
  • Tolerance: ±0.50 mm/ 95% in tolerance.
  • Janka hardness rating: 1500 lbf (6670 N).
  • Thermal conductivity: 0.10 m²K/W (1.0 Tog).
  • Tonal variation: Medium natural.
  • Thickness: 19 mm.
  • Length: Random, up to 1.4 m.
  • Tone: Dark.

- Delamere (all):

  • Wood species: Douglas fir.
  • Grade: Nature.
  • Wear layer: 6 mm hardwood (nominal).
  • Finish: Unfinished - site preparation required.
  • Tolerance: ±0.75 mm/ 95% in tolerance.
  • Janka hardness rating: 620 lbf (2760 N).
  • Thermal conductivity: 0.10 m²K/W (1.0 Tog).
  • Tonal variation: Medium natural.
  • Thickness: 20 mm.
  • Length: Random, up to 3.00 m.
  • Tone: Neutral.

- Rockingham (all):

  • Wood species: American black walnut.
  • Grade: Prime.
  • Wear layer: 6 mm hardwood (nominal).
  • Finish: Matt hardwax oil or unfinished.
  • Tolerance: ±0.50 mm/ 95% in tolerance.
  • Janka hardness rating: 1010 lbf (4500 N).
  • Thermal conductivity: 0.10 m²K/W (1.0 Tog).
  • Tonal variation: Low natural.
  • Thickness: 20 mm.
  • Length: Random, up to 1.83 m.
  • Tone: Dark.

- Winterfold:

  • Wood species: Pippy Burr oak.
  • Grade: Nature.
  • Wear layer: 4 mm hardwood (nominal).
  • Finish: Unfinished - site preparation required.
  • Certification: FSC 100%.
  • Tolerance: ±0.50 mm/ 95% in tolerance.
  • Janka hardness rating: 1120 lbf (4980 N).
  • Thermal conductivity: 0.08 m²K/W (0.8 Tog).
  • Tonal variation: Medium natural.
  • Thickness: 15 mm.
  • Length: Random, up to 1.90 m.
  • Tone: Mid.
