Soundis Routed Insulation XPS - Under Floor Heating Panel
Verified by manufacturer 1 month ago
CHAS
Certificate type
Constructionline Gold
Certificate type
smas WORKSAFE
Certificate type
Acclaim Accreditation
Certificate type
High compressive strength underfloor heating floorboard.
Application
High compressive strength underfloor heating floorboard.
Description
Soundis XPS Integral is a CNC routed, 100-micron aluminium foil faced expanded polystyrene panel. The standard panel is offered with a variety routing patterns and faced with a highly conductive aluminium foil for efficient heat transfer.
Features and benefits:
- Pre-grooved for all types of 12–16 mm UFH pipe.
- Option of 100 micron aluminium facing foil.
- High compressive strength.
- Thermal conductivity 0.033–0.036 W/mK.
- Works in conjunction with acoustic treatments.
For more information contact manufacturer
General information
Color | Yellow Silver |
Finish | Smooth |
Material | High density extruded polystyrene (XPS) |
Shape | Rectangle |
Length | 1200 mm 2400 mm |
Width | 300 mm 600 mm 1200 mm |
Height | 18 mm 20 mm 25 mm 30 mm 35 mm |
Uniclass | |
CAWS | M10/290 Floating construction |
Specification data - Extruded polystyrene (XPS) boards
Compressive strength (minimum) at 10% compression | 200 kPa.300 kPa. |
Thermal conductivity (maximum) | 0.033 W/mK. |
Thickness | 18 mm.20 mm.25 mm.30 mm.35 mm.40 mm.50 mm.Manufacturer guidanceConsult manufacturer for insight into the correct pipe diameter per thickness. |
Face size (length x width) | 300 x 1200 mm.600 x 1200 mm.1200 x 1200 mm.300 x 2400 mm.600 x 2400 mm.1200 x 2400 mm. |
Edges | Square. |
Centres | 150 mm. 200 mm. 300 mm. Manufacturer guidancePipe centres. |
Pipe diameter | 12 mm. 14 mm. 15 mm. 16 mm. 18 mm. Manufacturer guidanceRoute sizes to suit pipe diameter. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
