Sonik Pivoting 52 Door Single

Sonik Pivoting 52 Door Single

Komfort Partitioning Ltd

Sonikdoors is a newly improved group which has been designed to focus on ease of installation and future product maintenance whilst ensuring high acoustic insulation is maintained.

Jump to:
+44 (0) 1403 390300 www.komfort.com
Description

Sonik Slide is an acoustic pocket double glazed sliding door, which can be within its own unique frameless glass partition. This is a top hung system which has been designed to focus on ease of door installation and future product maintenance, whilst ensuring a high acoustic performance is maintained.

Performance of completed system:

  • Fire resistance to BS 476-22: Non-rated.
  • Spread of flame, to BS 476-7: Class 1.

Frame installation and glazing to be carried out by Komfort approved installer - consult manufacturer for details.

General information
Finish

Powder coated finish

Features

Multiple door options available, ease of installation, multiple thicknesses available

Material

Glass, aluminium

Size

2700 x 1100 mm

Uniclass 2015
Pr_25_71_57_60 Partition panelsPrimary
Specification data - Partition panels
Product Reference

Komfort Sonik Slide Partition

Fire propagation to BS 476-6

Non-rated

Class 0 (England/ Wales/ N. Ireland)

Low risk (Scotland)

Accessories

None

Graphics

Framework -
Finish

Kolourframe polyester powder coated

Special anodized finish

Doorset -
Type

Sonik double glazed pocket sliding door to 34 dB (Rw)

Fire rating

Non-rated

Finish

Double glazed framed glass door

Glazed panels -
Glass

Double glazed 10 mm toughened +10.8 mm acoustic laminated

Double glazed 10.8 mm acoustic laminated + 12.8 mm acoustic glass

In-line

Bubble joint (SJ34)

ProductInformation

https://www.komfort.com/wp-content/uploads/2018/09/Komfort_Brochure_Web-FINAL.compressed.pdf

Standard product features

Door weight (maximum):

120 kg.

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
Revit 2017 1 2.1
Download now from NBS National BIM Library
Literature
