SonaSpray fcx - Acoustic Spray Plaster

Verified by manufacturer 3 days ago

SonaSpray fcx - Acoustic Finish 6 mm

Oscar Acoustics Variant:
Third party certifications:
  • Warringtonfire

    Warringtonfire

    Certificate type

  • GreenGuard Gold

    GreenGuard Gold

    Certificate type

  • M1 emission classification

    M1 emission classification

    Certificate type

  • EPD

    EPD

    Certificate type

  • Cradle to Cradle Certified

    Cradle to Cradle Certified

    Certificate type

  • LEED US

    LEED US

    Certificate type

  • HPDC Certification

    HPDC Certification

    Certificate type

  • FSC

    FSC

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • CHAS

    CHAS

    Certificate type

Sprayed and trowelled flat finish with attractive lightly pitted surface.

Jump to:
BOS
+44 (0)1474 854902 Website

Application

An acoustic plaster particularly suitable for noise reverberation control in offices, homes, swimming pools, public places, classrooms and restaurants.


Please note that it is important not to use moisture resistant plasterboard as this can cause staining of wet applied products. Oil based stain barrier paints can be used to prevent this. Please consult Oscar Acoustics for more information.


A minimum of 12.5 mm thick plasterboard, installed to British Gypsum specification should be used.


Acoustic spray application by Oscar Acoustics trained in-house teams. Consult Oscar Acoustics for relevant acoustic plaster preparation details.

Description

Sprayed and trowelled, flat acoustic plaster finish with an attractive, lightly pitted, seamless surface for noise reverberation control.

A flat, very lightly pitted surface coating. Naturally safe, recycled cellulose fibre, with low embodied energy. Can be disposed of as non-hazardous waste. Acoustic plaster can be applied directly onto plasterboard, smooth concrete, steel sheet and most other surfaces. Suitable for flat, domed and vaulted soffits.

An excellent alternative to acoustic panel ceilings without design compromise.


Features and benefits:

  • SonaSpray is a recycled acoustic spray and acoustic plaster product range that not only satisfy sustainable design certification systems like BREEAM, SKA, Living Building Challenge and LEED, they also tick every box for indoor environmental and air quality.
  • SonaSpray acoustic sprays and acoustic plasters are M1 Classified as Low Emitting Building Materials (the top achievable class), are compliant with CDPH/CA Section 01350 and are GREENGUARD Gold Certified for Indoor Air Quality.
  • GREENGUARD Gold Products are now confirmed to show compliance with BREEAM rating system HEA Indoor Air Quality and ensure that a product has met some of the world’s most rigorous and comprehensive standards for low emissions of VOC’s into indoor air. The acoustic spray and acoustic plaster range is also covered by an Environmental Product Declaration in accordance with ISO 14025.
  • All these credentials enable the SonaSpray acoustic spray and acoustic plaster range to contribute towards satisfying many features under the WELL Building Standard®: an international performance-based system for measuring, certifying and monitoring features of the built environment that impact human health and wellbeing, through air, water, nourishment, light, fitness, comfort and mind, with a mission to improve human health and wellbeing through the built environment.
  • The acoustic plaster adhesive provides a strong, durable and resilient bond.
  • Acoustic plaster can be applied to virtually any substrate configuration.
  • Noise reduction insulation insulates by creating dead air macroscopic spaces between and within the hollow cellulose fibres.


Fire rating:

B-s1,d0 and Class 0 to BS 476 - significantly betters the requirements of the new Approved Document B providing little to no smoke and absolutely no droplets, assisting in the safe escape of occupants.


Emissions:

  • M1 emission class certified for building materials (best class).
  • Compliant with CDPH/CA Section 01350.
  • GREENGUARD Gold Certified for Indoor Air Quality.
  • BREEAM rating system HEA Indoor Air Quality.
  • WELL Building Standard®.


Environmental standards:

  • Environmental Product Declaration in accordance with ISO 14025 - EN 15804. Living Building Challenge compliant.
  • Living Building Challenge compliant.
  • BREEAM.
  • LEED.
  • SKA.


Flange fittings:

90% of flangeless fittings do not work properly with any acoustic finish. If you are specifying a flangeless fitting, please contact Oscar Acoustics for advice.


Sound absorption:

Acoustic testing has been carried out against concrete. Substrates likely to provide increased performance include plasterboard with the use of an air gap behind, rib deck or profiled metal sheet. Please contact Oscar Acoustics’ technical department for free design assistance.


Embodied carbon:

Can effectively lower the carbon footprint of a building project by sequestering rich stores of carbon for the life of the structure or application


Colours:

Arctic White, White (non-stock), bespoke colours are available, minimum quantities apply.

General information

Color

White

Guidance for specification option:

Artic White.

Other

Guidance for specification option:

Bespoke colours are available, minimum order quantities apply.

Manufacturer guidance

Bespoke colours are available, minimum order quantities apply.

Finish

Smooth

Manufacturer guidance

Sprayed & trowelled, flat acoustic plaster finish with an attractive, lightly pitted, seamless surface.

Material

Paper

Guidance for specification option:

Recycled high grade.

Uniclass

Ss_25_45_85_85 Sprayed internal monolithic coating systemsPrimary

CAWS

M22/120 Sprayed

Product range

Acoustic plasters
Acoustic sprays

Specification data - Sprayed internal monolithic coating systems

System performance

Reaction to fire to BS EN 13501-1, B-s1, d0 and Class 0 to BS 476.

Guidance for specification option:

Significantly betters the requirements of the new Approved Document B providing little to no smoke and absolutely no droplets, assisting in the safe escape of occupants.

Preparation

In accordance with OEL3 Oscar pre-start check list.

Coating

-

Binding agent

Water based adhesives.

Insulant

Cellulose fibre.

Guidance for specification option:

Coating insulant - R 0.03 per mm (W/m·K).

Movement joints

-

Form with

Stop bead.

Guidance for specification option:

Only required when passing over existing building movement joints.

Accessories

None.

Bespoke access hatches.

Oscar Evo-Blade razor edge trim.

Recessed light Halos (flanged fitting only).

Guidance for specification option:

For downlighters, etc. Can be specially manufactured by Oscar for each project.

Pattresses.

Stop bead.

Surface finish

SonaSpray fcx trowel finish.

SonaSpray fcx lightly stippled finish.

Colour

Arctic white.

Guidance for specification option:

Held in stock.

Special order.

Guidance for specification option:

Bespoke colours are available, minimum quantities apply.

System manufacturer

ICC.

Thickness

6 mm.

Weight

1.35 kg/m².

Sound absorption coefficient

To BS EN ISO 354 at 125 Hz: 0.05, at 250 Hz: 0.10, at 500 Hz: 0.40, at 1 kHz: 0.70, at 2 kHz: 0.85, at 4 kHz: 0.90.

Noise reduction coefficient

0.50.

Weighted sound absorption coefficient

0.40 αw.

IndoorEnvironment

M1 emission class certified for building materials (best class), compliant with CDPH/CA Section 01350 / GREENGUARD Gold Certified for Indoor Air Quality / BREEAM rating system HEA Indoor Air Quality / WELL Building Standard®.

Environmental

Environmental Product Declaration in accordance with ISO 14025 - EN 15804. Living Building Challenge compliant / BREEAM / LEED / SKA.

Sustainability data

Contains Red List materials

No

Country of material origin

United States

Country of product manufacture

United States

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

2.09 kg CO₂ eq/kg

Guidance for specification option:

Can effectively lower the carbon footprint of a building project by sequestering rich stores of carbon for the life of the structure or application.

Manufacturer guidance

Can effectively lower the carbon footprint of a building project by sequestering rich stores of carbon for the life of the structure or application.

Recyclability

100%

Manufacturer guidance

Future reconstruction of buildings may require removal of acoustic spray. SonaSpray can be recycled or disposed of as a non-special waste and your local authority waste disposal will be able to give advice on recycling.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

80 %

Guidance for specification option:

SonaSpray fibres are made up of minimum 80% post-consumer recycled high grade paper.

EPD

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

4

IFC
-

4

Third party certifications

Warringtonfire

Warringtonfire

Fire - BS 476 Part 6: 1989 A1: 20090 (SonaSpray)

Warringtonfire

Warringtonfire

Fire - BS 476 Part 7: 1997 (Oscar Evo-Panel)

Warringtonfire

Warringtonfire

Fire - Class 0 & 1 to BS476 (SonaSpray)

Warringtonfire

Warringtonfire

Fire - EN 13501 (SonaSpray)

Warringtonfire

Warringtonfire

Fire - Class 0 Summary - Report Compliance with the requirements for A class 0 surface - Oscar Evo-Panel

GreenGuard Gold

GreenGuard Gold

GREENGUARD Gold - SonaSpray fcx - Exp 05 Jul 24

M1 emission classification

M1 emission classification

SonaSpray M1 emission classification

EPD

EPD

EPD - SonaSpray fcx - Environmental Product Declaration
