SoftSound® Liner System
Decorative wall panelling.
- Commercial premises.
- High traffic public areas.
- Call centres.
- Offices and conference centres.
- Reception areas.
- Education facilities.
- Healthcare buildings.
- Recording studios.
- Theatres, cinemas and auditoria.
Decorative wall panelling, manufactured from a sound absorbing mineral fibre core board faced with a thin, high-density, impact resistant mineral fibre panel. The composite panel is then wrapped with an acoustically transparent fabric. Locating channels are also wrapped in matching high quality fabric.
Features and benefits:
- Absorbs high levels of reflected noise and significantly reduces reverberation.
- Wide range of applications.
- Design flexibility: complete floor to ceiling coverage is possible.
- High quality decorative finish.
- Available in a range of bespoke sizes.
- Easy to install.
Applications:
- Commercial premises.
- High traffic public areas.
- Call centres.
- Offices and conference centres.
- Reception areas.
- Education facilities.
- Healthcare buildings.
- Recording studios.
- Theatres, cinemas and auditoria.
Fire performance:
Cara, Lucia and Lucia CS fabrics meet the requirements of Class 1 Surface Spread of Flame when tested to BS 476-7: 1997 (As Amended).
Acoustic performance:
Consult manufacturer's literature for details.
Finish | Cara fabric Insert colour requirements. Lucia CS fabric Insert colour requirements. Lucia fabric Insert colour requirements. Bespoke Subject to fabric being of a suitable quality and having the required acoustic properties. Consult manufacture and insert requirements. |
Uniclass 2015 | |
CAWS | K13/170 Acoustic panel lining |
Product Reference | SoftSound® Liner System |
Height | Insert requirements, maximum 2700 mm. |
Width | Insert requirements, maximum 1215 mm. |
Thickness | 25 mmAbsorber classification (to BS EN ISO 11654): C. 50 mmAbsorber classification (to BS EN ISO 11654): A. |
Finish | Cara fabricInsert colour requirements. Lucia CS fabricInsert colour requirements. Lucia fabricInsert colour requirements. BespokeSubject to fabric being of a suitable quality and having the required acoustic properties. Consult manufacture and insert requirements. |
Standard product features | Thermal conductivity: 0.033 W/m·K at 10°C. Fixing: Secured within perimeter locating channels that are fixed to the substrate. Panels have fabric wrapped vertical sides to provide a neat butt joint finish. |
