SMARTPLY PROPASSIV OSB - OSB

MEDITE SMARTPLY Third party certifications:
  • FSC

    FSC

    Certificate type

  • EMS ISO 14001

    EMS ISO 14001

    Certificate type

  • QMS ISO 9001

    QMS ISO 9001

    Certificate type

  • Environmental Product Declaration (EPD) – IGBC

    Environmental Product Declaration (EPD) – IGBC

    Certificate type

Structural airtight OSB3 panel with integrated vapour control properties.

Jump to:
+44 (0)1322 424900 Website

Application

The product is suitable for both new build and renovation projects.

Description

Structural airtight OSB3 panel with integrated vapour control and air barrier properties for use as structural sheathing in timber frame structures.

Airtightness is engineered into the OSB panel substrate, whilst SMARTPLY's in-house speciality surfacing technology provides an integrated vapour barrier with consistently high vapour resistance over the entire surface.

The coating also provides a smooth durable surface for superior bonding of airtight tape at panel joints. SMARTPLY PROPASSIV provides a sustainable and robust alternative to specialist AVCL membranes which are prone to damage by site trades during the construction process.


Features and benefits:

  • Airtightness engineered into OSB substrate with specialist surfacing technology providing integrated vapour barrier and ideal surface for adhesion of tapes on the joints.
  • Easy to cut and fix.
  • Rigid panel - less susceptible to damage than membranes.
  • Consistently high vapour resistance.
  • Durable smooth surface.
  • High racking strength.
  • Zero added formaldehyde.
  • Manufactured from FSC® timber from MEDITE SMARTPLY's own forests-assured supply of sustainable raw material.
  • Equivalent air layer thickness (sd) (to BS EN 12572): Dry cup: 9.4 m (±1.0); Wet cup: 5.2 m (±1.0).
  • Air permeability coefficient at 50 Pa (tested to EN 12114): < 0.005 m³/(h.m²).

General information

Finish

Smooth

Material

Timber

Shape

Rectangle

Length

2397 mm

Width

1197 mm

Uniclass

Pr_25_71_97_58 Oriented strand boardsPrimary

CAWS

K11/35 Oriented strand board flooring

K11/435 Oriented strand board wall sheathing

Product range

SMARTPLY OSB range

Specification data - Oriented strand boards

Thickness

12.5 mm.

Size (l x w): 2397 x 1197 mm.

MoistureContent

4–9%.

To BS EN 322.

Density

620 kg/m³.

To BS EN 323.

Formaldehyde emissions

Class E1.

Release of formaldehyde (to BS EN 13986).

ThermalConductivity

0.1 W/m·K.

To BS EN 13986.

Water vapour diffusion resistance - µ value

Dry cup: 750 (±80); Wet cup: 420 (±40).

To BS EN 12572.

Air permeability

<0.001 m³/m²/h/Pa (at 50 Pa).

Environmental information

Contains Red List materials

No

Country of material origin

Ireland

Country of product manufacture

Ireland

BIM objects

Platform Compatible Version
Revit

Revit 2017

1

IFC
-

1

Literature

SMARTPLY PROPASSIV - The First Airtight board certified by PassivHaus

SMARTPLY PROPASSIV - The First Airtight board certified by PassivHaus

Modern Methods of Construction Guide

Modern Methods of Construction Guide

Case studies

SMARTPLY PROPASSIV Plays An Active Role In Architect's Passive House

SMARTPLY PROPASSIV Plays An Active Role In Architect's Passive House

SMARTPLY PROPASSIV used for Passivhaus in Cork

SMARTPLY PROPASSIV used for Passivhaus in Cork

Third party certifications

FSC

FSC

FSC SMARTPLY

EMS ISO 14001

EMS ISO 14001

SMARTPLY - ISO 14001

QMS ISO 9001

QMS ISO 9001

SMARTPLY -IS0 9001

Environmental Product Declaration (EPD) – IGBC

Environmental Product Declaration (EPD) – IGBC

SMARTPLY EPD
