Structural airtight OSB/3 panel with integrated vapour control properties.
The product is suitable for both new build and renovation projects.
Structural airtight OSB/3 panel with integrated vapour control and air barrier properties for use as structural sheathing in timber frame structures.
Airtightness is engineered into the OSB panel substrate, whilst SMARTPLY's in-house speciality surfacing technology provides an integrated vapour barrier with consistently high vapour resistance over the entire surface.
The coating also provides a smooth durable surface for superior bonding of airtight tape at panel joints. SMARTPLY AIRTIGHT provides a sustainable and robust alternative to specialist AVCL membranes which are prone to damage by site trades during the construction process.
Features and benefits:
Color | Green |
Finish | Smooth |
Material | Oriented strand board (OSB) |
Shape | Rectangle |
Length | 2397 mm |
Width | 1197 mm |
Uniclass | |
CAWS | K11/35 Oriented strand board flooring K11/435 Oriented strand board wall sheathing |
Product range |
Thickness | 12.5 mm.Guidance for specification option: Size (l x w): 2397 x 1197 mm. |
MoistureContent | 4–9%. Guidance for specification option: To BS EN 322. |
Density | 620 kg/m³. Guidance for specification option: To BS EN 323. |
Formaldehyde emissions | Class E1. Guidance for specification option: Release of formaldehyde (to BS EN 13986). |
ThermalConductivity | 0.1 W/m·K. Guidance for specification option: To BS EN 13986. |
Water vapour diffusion resistance - µ value | Dry cup: 750 (±80); Wet cup: 420 (±40). Guidance for specification option: To BS EN 12572. |
Air permeability | <0.001 m³/m²/h/Pa (at 50 Pa). |
Contains Red List materials | No |
Country of material origin | Ireland |
Country of product manufacture | Ireland |
Material | Oriented strand board (OSB) |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
