Slido D-Line11 160P - Door accessories

Verified by manufacturer 6 months ago

Hafele UK Ltd

Sliding door mechanism.

Jump to:
+44 (0)800 171 2907 Website

Application

Suitable for commercial and residential interior doors.

Description

Smooth running quality system for commercial and residential interior doors.


Features and benefits:

  • Fitting sets are for one door, without soft close.
  • Trolley hangers have four ball bearing rollers.
  • Maximum door weight: 160 kg.
  • Door height adjustment: ± 5 mm.
  • Suspension fitting with screwed-on support flange.
  • For one and two leaf sliding doors.
  • Tested to BS EN 1527:2013, 100 000 cycles.

General information

Color

Silver

Finish

Anodized

Material

Aluminium

Length

2000 mm

3000 mm

Height

36.5 mm

Warranty description

Seven year

Uniclass

Pr_30_36_36_23 Door track and running gearPrimary

CAWS

P21/10 Door track and running gear

P21/350 Door track and running gear

Product range

Sliding Door Gear

Specification data - Door track and running gear

Standard

To BS EN 1527:2019.

Integral accessories

None

Soft Close Set available as special order for doors minimum 868 mm wide.

Product Reference

Slido D-LINE11 160P

Mounting

44 mm bracket, 940.62.061.

64 mm bracket, 940.42.063.

2000 mm top track, 941.62.721.

3000 mm top track, 941.62.731.

Clip panel

Not required.

2000 mm, 940.43.120.

3000 mm, 940.43.130.

Fitting set

941.62.009.

Guidance for specification option:

  • Running gear, four rollers, support flange for screw fixing, galvanized steel.
  • Track buffer, with retaining spring and rubber buffer.
  • Floor guide, grey plastic.

Sustainability data

Country of material origin

Germany

Country of product manufacture

Germany

Literature

Häfele Slido Brochure

Häfele Slido Brochure

Slido D-Line11 160P
