Sliding Glass Rooflight

Verified by manufacturer 3 months ago

Surespan

Sliding glass rooflight.

Jump to:
+44 (0)1922 711185 Website

Description

Sliding glass rooflight, incorporating double seals with a unique sealing feature which 'lifts off' the upstand on opening and re-seals on closing.


Telescopic sliding covers are ideal for smaller sizes that only require access for maintenance personnel or end-users. These are available in sizes of up to 750 x 2500 mm. Fixed sliding covers can be made to any size without limit; they are ideal for large equipment access as they provide the maximum clear opening.


Features and benefits:

  • Custom-made to any size.
  • Fully insulated and energy-efficient.
  • Internal telescopic rails available.
  • Insulation U-value of 0.43 W/m²K.
  • Mill-finish aluminum frame as standard; powder coating optional.

General information

Material

Aluminium

Stainless steel

Glass

Uniclass

Pr_30_59_72_31 Framed rooflightsPrimary

CAWS

L10/45 Rooflights

L10/460 Rooflights

Product range

Roofing

Specification data - Framed rooflights

Size

Guidance for specification option:

Insert requirement.

Accessories

None.

Glazed top.

Rain skirt.

Retractable ZIP ladder.

Guidance for specification option:

To suit floor to ceiling height up to 3.5 m.

SureGrip non-slip finish.

SureGuard handrail.

Wind and rain sensors.

Locking

None.

DBH Lock, standard internal slam-action cablock.

Guidance for specification option:

Deadlock with internal handles.

EDH Deadlock, internally and externally key-opening.

Electrical locking.

Operation

24 V electric motors.

Gas springs.

Guidance for specification option:

Standard.

External

Mill.

Guidance for specification option:

Standard.

Polyester powder-coated.

Guidance for specification option:

Insert RAL colour requirement.

Internal

Mill.

Guidance for specification option:

Standard.

Polyester powder-coated.

Guidance for specification option:

Insert RAL colour requirement.

Rails

Fixed.

Telescopic.

Insulation

The lid is filled with 50 mm-thick CFC- and HCFC-free polyisocyanurate insulation, which offers a U-value of 0.43 W/m²K, a GWP (global warming potential) of 3 and an ODP (ozone depletion potential) of 0.

Upstand

300 mm in height and manufactured in aluminum, with a 50-mm insulation thickness.
