Skyline (Floor to Ceiling) HPL WC Cubicle - Full Height HPL Cubicle

Name: Skyline (Floor to Ceiling) HPL WC Cubicle - Full Height HPL Cubicle
Brand: Excelsior Panelling Systems Ltd
SKU: 3PjqKmbnqe4vdGjShPbQzm

Verified by manufacturer 3 months ago

Skyline SGL WC Cubicle 2700 mm High

Excelsior Panelling Systems Ltd

Third party certifications:

ISO 9001 Quality Management
Certificate type
Constructionline
Certificate type
CHAS
Certificate type
EPD
Certificate type

Elegant and discreet full height cubicle system

Jump to:

BOS

+44 (0)1384 267770 Website

Application

Washrooms

Description

Meeting the demands of modern education and mixed use environments, Skyline is a floor to ceiling system providing the user with maximum privacy and comfort. A full range of

complimentary duct panels and vanity units are available on request. Outward opening doors complete with back to back Aluminium ‘D’ Handles and full height ‘Z’ Section door Stop/Keep.

Suitable for locations where greater user privacy is required.

The Skyline system is an extension of the

proprietary height cubicle systems providing a floor to ceiling application with an aluminium floor channel or

an alternative pedestal leg option to create a standard floor clearance.

General information

Material	High pressure laminate (HPL)
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	2700 mm Bespoke

Uniclass	Ss_25_12_60_60 Panel cubicle systemsPrimary
CAWS	K32/120 Panel cubicles K32/10 Panel cubicles

Specification data - Panel cubicle systems

Panels	High Pressure Laminated PUR bonded onto 18 mm MR core.
Panel supports	Leg 50 mm. Leg 100 mm. Leg 150 mm. Floor Channel to Divsions.
Pilasters	High Pressure Laminated PUR bonded onto 18 mm MR core.
Doors	High Pressure Laminated PUR bonded onto 18 mm MR core.
Lippings	Black core radius and polished edge finish.
Hardware	Manufacturer's standard. Guidance for specification option: Ironmongery: Excelsior Semi Bright Anodized Aluminium as standard Rise and fall aluminium hinges Ref: EXH-AT13 Recessed Indicator and Keep - Ref: EXL-A13 Coat Hook - Ref: EXCH-A13 Brackets - 20 mm SAA Division U-Channel / Wall Pilaster J-Channel Headrail Ref: EXPHR13 Division base rail 20 mm SAA U-Channel Toilet Roll Holders and Accessories available upon request.
System accessories	- Manufacturer guidance Toilet roll holders and accessories available upon request.

Size:	2700 mm overall height x 1500 mm deep.
Colour/ Finish:	- Manufacturer guidance Excelsior Preferred Cubicle & Washroom colour selections.

Sustainability data

Country of material origin	Europe
Country of product manufacture	United Kingdom
Manufacturing plant location	Dudley DY2 0RL, UK
Material	High pressure laminate (HPL)
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
