Sikaplan® G Single Ply Membrane (Mechanically Fixed Warm Roof System)

Verified by manufacturer 16 days ago

Sikaplan® Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Mechanically-fixed warm roof system based around the Sikaplan® G membrane.

Jump to:
+44 (0)1707 394444 Website

Application

Mechanically fixed warm roof system.

Description

Mechanically-fixed warm roof system based around the Sikaplan® G membrane.


Features and benefits:

Sikaplan® G is a polyester reinforced multilayer, synthetic roof waterproofing sheet based on premium-quality polyvinyl chloride (PVC) according to EN 13956.


USES

Waterproofing membrane for exposed flat roofs:

  • Mechanically fastened roofing systems.
  • Detailing.


CHARACTERISTICS / ADVANTAGES

  • Resistant to permanent UV irradiation.
  • Resistant to permanent wind exposure.
  • High water vapour permeability.
  • Resistant to all common environmental influences.
  • Hot air welding without use of open flames.
  • Recyclable.


ENVIRONMENTAL INFORMATION

  • Environmental Product Declaration (EPD) available.


APPROVALS / STANDARDS

  • BBA Agrement Certification (09/4668).
  • EN13501-5 Broof(t4) (as part of system).
  • Polymeric sheets for roof waterproofing according to EN 13956, certified by notified body 1213-CPD-4125/4127 and provided with the CE-mark.
  • Reaction to fire according to EN 13501-1. Class E (membrane alone).
  • Factory Mutual (FM) Approval Class: 4470.
  • Quality Management system in accordance with EN ISO 9001/14001.

General information

Color

Grey

Finish

Smooth

Material

Polyvinyl chloride (PVC)

Shape

Rectangle

Length

20000 mm

Width

2000 mm

Height

1.5 mm

1.8 mm

Warranty description

15 year

20 year

25 year

Uniclass

Ss_30_40_30_80 Single layer sheet warm roof covering systemsPrimary

CAWS

J42/10 Warm deck roof covering

J42/110 Warm deck roof covering

Specification data - Single layer sheet warm roof covering systems

Preparation

-

Horizontal work

-

Manufacturer guidance

Consult manufacture's literature for full technical details.

Air and vapour control layer

-

Type

S-Vap®-500 E.

Guidance for specification option:

Unsupported vapour control layer. Not suitable for temporary or permanent waterproofing.

  • Carrier: Low-density polyethylene (PE-LD) foil.
  • Effective thickness, to EN 1849-2: 0.15 mm (±20%).
  • Mass per unit area, to EN 1849-2: 0.145 kg/m² (±15%).
  • Surface colour/ finish: White, smooth.
  • Length (per roll), to EN 1848-2: 25 m ±2%..
  • Width, to EN 1848-2: 5 m ±1%.

Manufacturer guidance

Consult manufacturer's literature for full technical details.

Attachment

Loose laid.

Insulation

-

Type

Sikatherm® PIR AL Polyisocyanurate (PIR) foam boards.

Sikatherm® PIR AL T Polyisocyanurate (PIR) foam boards.

Sikatherm® MW DD Mineral wool slab insulation.

Sikatherm® MW DD T Mineral wool slab insulation.

Manufacturer guidance

Consult manufacturer's literature for full technical details.

Attachment

Mechanically fixed with appropriate Sika Limited mechanical fasteners (in accordance with Sika Limited Technical Guidance).

Waterproof covering

-

Type

Sikaplan® G-15.

Sikaplan® G-18.

Manufacturer guidance

Consult manufacturer's literature for full technical details.

  • Product declaration to EN 13956: 2005.
  • Surface: Smooth.
  • Colour (bottom surface): Dark grey.
  • Length, to EN 1848-2: 15 m (-0%/ +5%).
  • Width, to EN 1848-2: Available in 0.6, 1.1 and 1.8 m (-0.5%/ +1%).
  • Straightness, to EN 1848-2: ≤30 mm.
  • Effective thickness, to EN 1849-2: 2.0 mm (-5%/ +10%).
  • Flatness, to EN 1848-2: ≤10 mm.
  • Reaction to fire, to EN 13501-1: Class E (EN ISO 11925-2).
  • External fire performance Part 1–4, to EN 13501-5: BROOF(t1)<20°/>20°.
  • Mass per unit area, to EN 1849-2: 2.5 kg/m² (-5%/ +10%).
  • Water tightness, to EN 1928: Pass.

Attachment

Mechanically fixed with appropriate Sika Limited mechanical fasteners (in accordance with Sika Limited Technical Guidance).

Guidance for specification option:

Consult manufacturer's literature for further details.

Joints

Guidance for specification option:

Consult manufacturer for options and insert requirements.

Accessories

Sikaplan® SG-15.

Sikaplan® G-15.

Sikaplan® D-18.

Sikaplan® Metal.

SikaRoof® PVC Welding Cord.

SikaRoof® S-Bar.

SikaRoof® C-733.

SikaRoof® Cleaner L-100.

SikaHyflex®-250 Facade.

System accessories

SikaRoof® S-Drain.

SikaRoof® S-Scupper.

SikaRoof® Light.

SikaRoof® Constant Force Post.

SFS SOTER® II Fall Protection.

SikaRoof® Solar Panel Support Anchor.

SikaRoof® PVC Lightning Conductor Clip.

Sikaplan® Walkway-20.

SikaRoof® SE Profile.

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

09/4668 - Product Sheet 4
