Shifting Fields Carpet Tile Collection: Plains Tile 5T472

Verified by manufacturer 8 days ago

71106

Shaw Contract Variant:
Third party certifications:
  • EPD

    EPD

    Certificate type

Carpet tile with a pet non-woven backing.

Jump to:
BOS
+44 (0)20 79614120 Website

Application

Recommended installation methods (product specific):

  • Monolithic; Quarter turn; Random; Brick; Ashlar.

Description

Carpet tile with a pet non-woven backing, available in 9 colours.


Features and benefits:

  • Use classification 33 Commercial Heavy EN1307.
  • Multi-level pattern loop, Eco Solution Q 100% solution dyed fibre.
  • Cradle to Cradle™ Bronze Certified and EPD available.
  • 15-year commercial limited warranty.
  • We want it back: At the end of its useful life, we’ll reclaim and recycle or reuse our carpet tiles through our reTURN scheme
  • Adhesive-Free Installation: IOBAC MagTabs™

General information

Color

Grey

Black

Red

Blue

Green

Finish

Tufted

Material

Nylon

Shape

Square

Length

500 mm

Width

500 mm

Height

7.3 mm

Warranty description

15 year

Uniclass

Pr_35_57_11_62 Pile carpet tilesPrimary

CAWS

M50/15 Carpet tiling

M50/130 Carpet tiling

Specification data - Pile carpet tiles

Style

Tufted loop pile.

Guidance for specification option:

1/10", 39.4 per 100 mm.

Material

Eco Solution Q® Polyamide 6.

Classification

-

Standard

To BS EN 1307.

Third-party certification

Cradle to Cradle: Bronze. Indoor air quality: A+ and Environmental product declaration.

Level of use class

To BS EN 1307, class 33.

Luxury rating class

LC1.

Recycled content

100%.

Size

500 x 500 mm.

Colour and pattern

Desert.

Dye method

100% solution dyed.

Primary backing

Pet non-woven.

Secondary backing

Taskworx® Tile, Polymer Modified Bitumen Eco Solution Q100™ Polyamide 6.

Total thickness

7.3 mm.

Mass

To ISO 8543, 4595 g/m².

Pile density

To ISO 8543, 0.122 g/m³.

Dimensional stability

To EN 986, ≤0.2%.

Sound insulation

To ISO 10140, 24 dB.

Sound absorption

To ISO 354/11654, 15 αw (Class E).

Thermal resistance

To ISO 8302, 0.073 m² K/W.

Colour fastness

To ISO 105-B02, >6.

FlammabilityRating

To EN 13501-1, Bfl-S1 (adhered testing).

Castor chair rating

To EN 985, ≥2.4.

Light reflectance

32.4.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %

EPD

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

1

Third party certifications

EPD

EPD

Shaw Contract Shaw Europe EPD
