Shelving - Spur Shelving
Verified by manufacturer 21 days ago
Adjustable shelves
Adjustable shelves
CHAS
Certificate type
Constructionline
Certificate type
Made in Britain
Certificate type
A shelving range for healthcare applications that includes adjustable shelves on brackets and a fixed mid storage shelf.
Application
Suitable for healthcare, education, veterinary, MOD, prison and dental applications.
Description
A shelving range for healthcare applications that includes adjustable shelves on brackets and a fixed mid storage shelf. The adjustable shelves are available in white melamine or laminate-faced MDF or chipboard. The mid storage shelf has rounded corners, an integrated 150 mm high backboard and is finished to match the storage cupboards.
Features and benefits:
- Compatible with other products in the David Bailey Healthcare furniture range.
- Available in a range of sizes.
General information
Color | White |
Finish | Other |
Material | Medium density fibreboard (MDF) Chipboard Melamine Solid grade laminate (SGL) |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year |
Uniclass | |
CAWS | N10/135 Storage and display units N10/130 Laboratory furniture |
Specification data - Shelves
Material | Chipboard laminate faced (white) with laminated edges.MDF laminate faced (white) with laminated edges.Chipboard melamine faced (white) with melamine ribbon edges.MDF melamine faced particleboard (white) with melamine ribbon edges.MDF laminate faced (colour) with laminated edges.Guidance for specification option: Insert colour requirements. Chipboard laminate faced (colour) with laminated edges.Guidance for specification option: Insert colour requirements. |
Dimensions | |
Length | 300 mm.350 mm.400 mm.450 mm.500 mm.550 mm.600 mm.650 mm.700 mm.750 mm.800 mm.850 mm.900 mm.950 mm.1000 mm.1050 mm.1100 mm.1150 mm.1200 mm.1250 mm.1300 mm.1350 mm.1400 mm.1450 mm.1500 mm.1550 mm.1600 mm.1650 mm.1700 mm.1750 mm.1800 mm.1850 mm.1900 mm.1950 mm.2000 mm.2050 mm.2100 mm.2150 mm.2200 mm.2250 mm.2300 mm.2350 mm.2400 mm.2450 mm.2500 mm.2550 mm.2600 mm.2650 mm.2700 mm.Manufacturer guidanceLengths in increments of 50 mm from 300 to 2700 mm. Insert requirements or refer to a drawing. |
Width | 200 mm.250 mm.300 mm.350 mm.400 mm.450 mm.500 mm.550 mm.600 mm. |
Thickness | 18 mm. |
Integral accessories | Adjustable shelf upright SMU/430.Guidance for specification option: 425 mm height. Adjustable shelf upright SMU/710.Guidance for specification option: 710 mm height. Adjustable shelf upright SMU/1000.Guidance for specification option: 1000 mm height. Adjustable shelf upright SMU/1220.Guidance for specification option: 1220 mm height. Adjustable shelf upright SMU/1600.Guidance for specification option: 1600 mm height. Adjustable shelf upright SMU/1980.Guidance for specification option: 1980 mm height. |
Brackets | Adjustable shelf brackets SB/120. Adjustable shelf brackets SB/170. Adjustable shelf brackets SB/220. Adjustable shelf brackets SB/270. Adjustable shelf brackets SB/320. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Medium density fibreboard (MDF) Chipboard Melamine Solid grade laminate (SGL) |
Recyclability | Non-reusable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Expected Life | 30 year |
Third party certifications
Literature
DBFS Healthline Healthcare Furniture
Merino Laminate Colour Chart
PFLEIDERER Laminate Colour Chart
Polyrey Laminate Colour Chart
Polyrey Laminate Pattern Colour Chart
Case studies
UCL Hospitals
