SGG Diamant
Application

  • Display cabinets.
  • Shelves.
  • Glass furniture (when laminated).
  • Table tops, bars and desk tops.
  • Shower screens.

Description

A colourless float glass with very low iron oxide content. As a result the glass has a very high light transmittance level and is significantly less green in appearance when compared to ordinary float glass. SGG Diamant allows a natural and true reproduction of white and pastel colours when enamelled, lacquered or screen printed.

Advantages:

  • Optimum transparency.
  • High neutrality in transmittance; optimized colour rendering and contrast.
  • Virtually colourless.
  • High energy transmittance for applications requiring the use of solar energy or high solar heat gain.
  • Beneficial for Window Energy Rating scenarios.

Applications:

  • Display cabinets.
  • Shelves.
  • Glass furniture (when laminated).
  • Table tops, bars and desk tops.
  • Shower screens.

Standards:

SGG Diamant extra clear float glass conforms to standard BS EN 572-2 and carries the relevant CE marking as required.

General information
Uniclass 2015
Pr_25_71_33_37 Heat-strengthened glass sheetsPrimary
CAWS

H10/10 Patent glazing

H10/115 Patent glazing

H11/110 Curtain walling

H13/115 Structural glass assembly

L40/210 Putty-fronted single-glazing

L40/230 Bead-fixed single-glazing

L40/250 Bead-fixed single-glazing

L40/260 Bead-fixed single-glazing

L40/310 Bead-fixed single-glazing

L40/330 Bead-fixed single-glazing

L40/350 Bead-fixed single-glazing

L40/370 Bead-fixed insulating glass units

L40/371 Bead-fixed insulating glass units

L40/372 Bead-fixed insulating glass units

L40/380 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/40 Putty-fronted single-glazing

L40/410 Single-glazing into grooves

L40/430 Single-glazing into grooves

L40/450 Single-glazing into grooves

L40/470 Zipper gasket glazing

L40/490 Single-sided gasket glazing

L40/50 Bead-fixed single-glazing

L40/530 Internal tape glazing

L40/55 Bead-fixed insulating glass units

L40/57 Bead-fixed insulating glass units

L40/58 Bead-fixed insulating glass units

L40/90 Internal tape glazing

Specification data - Heat-strengthened glass sheets
Product Reference

SGG Diamant

Thickness

4 mm

5 mm

6 mm

8 mm

10 mm

12 mm

15 mm

19 mm

Standard product features

Size (maximum w x l):

3210 x 6000 mm.

Processed products:

SGG Diamant is used as the substrate glass for a variety of other processed products; laminated safety glass, toughened safety glass; screen printed, enamelled or lacquered glass, anti-reflective glass and coated glass.
