Application

  • Offices and commercial buildings.
  • Industrial buildings.
  • Curtain walling facades.
  • Schools and hospitals.
  • High-end conservatories and skylight glazing.

Description

SGG Cool-Lite Xtreme 60/28 from Saint-Gobain Glass is a high performance solar control glazing. It is a triple-silver layered solar control glass offering an excellent ratio between light transmission and solar control. Ideal for use in commercial glazing where light transmittance is important but the need to keep solar heat out in the summer months, and retain internal heat in the winter months, is also a factor. SGG Cool-Lite Xtreme 60/28 is suited for all types of commercial buildings where large areas of glazing are required.

Advantages:

  • SGG Cool-Lite Xtreme 60/28 features an excellent selectivity of 2.14.
  • The level of natural light is very high at 60% while the solar heat gain is extremely low with a g-value as low as 0.28.
  • Excellent U-values of 1.0 W/m²K.
  • A high degree of neutrality both in transmission and exterior reflection.
  • Available in both annealed and 'to be toughened' versions*.
  • Ideal for large façades and atria glazing where the neutral coating allows light through but reduces heat transfer through the glass.

Applications:

  • Offices and commercial buildings.
  • Industrial buildings.
  • Curtain walling facades.
  • Schools and hospitals.
  • High-end conservatories and skylight glazing.

Standards:

SGG Cool-Lite Xtreme products meet the durability requirements of European Standards EN 1096-1 and -2, Class C.

General information
Specification data - Heat-strengthened glass sheets
Product Reference

SGG Cool-Lite Xtreme 60/28

SGG Cool-Lite Xtreme 60/28 II

Outer pane -
Thickness

6 mm

8 mm

10 mm

12 mm

Processing

Edgeworked

Heat-strengthened

Laminated

Toughened

Toughened and heat soak tested

Inner pane -
Type

SGG Diamant

SGG Planiclear

SGG Stadip

SGG Stadip Silence

SGG Seralit

SGG Emalit

Thickness

6 mm

6.8 mm

7.5 mm

8 mm

8.8 mm

9.5 mm

10 mm

10.8 mm

11.5 mm

12 mm

12.8 mm

13.5 mm

14.8 mm

16.8 mm

17.5 mm

Standard product features

Colour:

The appearance in reflection of SGG Cool-Lite Xtreme 60/28 is very neutral.

Standard size (w x l):

3210 x 6000 mm.

Product Options

Processing:

Though the main function of SGG Cool-Lite Xtreme 60/28 is solar control, it has additional thermal insulation. Available in annealed and 'to be toughened' forms to be used in double glazed units. The products can be toughened, heat-strengthened, edgeworked. Contact manufacturer for details.
