SG Edge Symmetry Door, Double Door Set, Non-rebated - Internal Doors

Name: SG Edge Symmetry Door, Double Door Set, Non-rebated - Internal Doors
Brand: Optima
SKU: u722TWMyTZTXFdiM3huDUa

Verified by manufacturer 5 months ago

Optima

Third party certifications:

BM Trada
Certificate type

A framed double-leaf, non-rebated, single-glazed acoustic glass door with high acoustic performance.

Jump to:

+44 (0)1494 492725 Website

Application

Suitable for offices and meeting rooms requiring a high level of acoustic privacy.

Description

The SG Edge Symmetry non-rebated double door set is a framed acoustic glass door which offers excellent acoustic performance and is ideal for meeting rooms requiring a high level of acoustic privacy.

Features and benefits:

Designed for use within the Microflush door frame and is pivoted.
Slim 30 mm standard width stile.
Part M-compliant clear opening included.

General information

Color	Silver White Other
Finish	Anodized Grained Polished Powder-coated
Material	Glass Aluminium
Width	Bespoke
Height	Bespoke
Warranty description	Ten year

Uniclass	Pr_30_59_24_02 Aluminium doorsetsPrimary
CAWS	L20/480 Doorsets L20/55 Doorsets

Product range	Door Leaves

Specification data - Aluminium doorsets

Configuration	As schedule. As drawing. Guidance for specification option: Insert drawing reference number.
Doorset size	- Manufacturer guidance Leaf only: 990 mm (single leaf). Overall frame width: 2050–2070 mm. Available up to 3000 mm in height.
Performance	-
Acoustic performance	33 dB. Guidance for specification option: (when used within a Microflush frame.) Manufacturer guidance (Rw, maximum):
Frame	-
Material	Aluminium.
Finish	-
Coating	Anodized. Grained. Guidance for specification option: Brightened and protective anodized. Polished. Guidance for specification option: Brightened and protective anodized. Powder-coated, RAL. Guidance for specification option: Insert requirement; contact manufacturer for more information. Powder-coated, RAL 9006 Silver. Guidance for specification option: 50 microns, 30% gloss (nominal). Powder-coated, RAL 9010 White. Guidance for specification option: 50 microns, 30% gloss (nominal).
Door leaf	-
Material	Glass.
Glazing	-
Type	Single-glazed,12 mm heat-soaked toughened glass (to BS EN 14179).
Manifestation	Guidance for specification option: Insert requirements.
Hardware	Guidance for specification option: Insert requirement; contact manufacturer for more information.

Operation	Hinges.
Samples required	Not required. Required.
System performance	Acoustic performance.

Sustainability data

Contains Red List materials	Yes
Country of product manufacture	United Kingdom
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	54.8 kg CO₂ eq/m² Self declared Guidance for specification option: See Environmental Product Declaration literature for detailed LCA data.
