Select Lockers (MFC Body & HPL Door) - Locker

Name: Select Lockers (MFC Body & HPL Door) - Locker
Brand: Excelsior Panelling Systems Ltd
SKU: aqSKck1vJUFFKiNhEX3yJ5

Verified by manufacturer 2 months ago

Excelsior Panelling Systems Ltd

Third party certifications:

CHAS
Certificate type
Constructionline
Certificate type
ISO 9001 Quality Management
Certificate type
EPD
Certificate type

MFC & HPL Lockers

Jump to:

BOS

+44 (0)1384 267770 Website

Application

Washrooms, leisure centres, offices, cloakrooms

Description

Panel Specifications:

Locker Bodies: Manufactured from 18mm Melamine Faced Chipboard with 2mm ABS to seen edges.

Locker Doors: High Pressure Laminate bonded 2 sides onto 18mm MR MDF with 2mm ABS edges.

Shelving: As Locker Bodies

Standard Dimensions Available:

Widths: 300mm, 400mm & 450mm ‘Z’ Type

Depths: 450mm & 500mm

Height: 1800mm

Available in Single tier including top shelf and double coat hook

2 Tier including dividing shelf and double coat hook

3,4,5,6 Tier lockers include dividing shelves

Bespoke Heights available upon request

Fittings / Ironmongery:

Hinges: Heavy Duty Cabinet Hinge with clip on action.

Assembly: CNC drilled components with Cam and Dowel fixing

Locking options: Cam Lock with 2 keys as standard and number disc to door (coin return, digital, combination, hasp and staple also available upon request).

Colour Selection: Excelsior Preferred Cubicle and Washroom HPL colour selections.

Special Notes: Bespoke locker plinths can be manufactured to suit individual requirements at an additional cost.

Integral and Complementary Benching available upon request.

General information

Finish	Laminated
Material	High pressure laminate (HPL)
Length	450 mm 500 mm Bespoke
Width	300 mm 400 mm 450 mm Bespoke
Height	1800 mm
Warranty description	Ten year

Uniclass	Pr_40_30_87_48 LockersPrimary
CAWS	N10/220 Lockers

Specification data - Lockers

Locker type	Single. Guidance for specification option: Single tier including top shelf and double coat hook 2 Tier. Guidance for specification option: 2 Tier including dividing shelf and double coat hook 3 Tier. Guidance for specification option: Includes dividing shelves 4 Tier. Guidance for specification option: Includes dividing shelves 5 Tier. Guidance for specification option: Includes dividing shelves 6 Tier. Guidance for specification option: Includes dividing shelves
Dimensions	300 x 450 x 1800 mm. 400 x 450 x 1800 mm. 450 x 450 x 1800 mm. 300 x 500 x 1800 mm. 400 x 500 x 1800 mm. 450 x 500 x 1800 mm. Manufacturer guidance Size (w x d x h).
Material	Locker bodies and shelving: Manufactured from 18 mm Melamine Faced Particleboard with 2 mm ABS to seen edges.  Locker Doors: High Pressure Laminate bonded two sides onto 18 mm MR MDF with 2 mm ABS edges.
Colour	- Manufacturer guidance Excelsior Preferred Cubicle and Washroom SGL colour selections.
Fittings	Heavy Duty Grass Cabinet Hinge with clip on action. Cam Lock with two keys and number disc to door. Guidance for specification option: Coin return, digital, combination, hasp and staple locking options also available upon request. Consult manufacturer for details and insert requirements. Manufacturer guidance CNC drilled components with Cam and Dowel fixing assembly

Sustainability data

Country of material origin	Europe
Country of product manufacture	Europe
Material	High pressure laminate (HPL)
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
