Secura Grand
BBA Agrément Certificate
Certificate type
EPD
Certificate type
A dry-build segmental retaining wall system using robust concrete blocks for the construction of taller or more heavily loaded gravity and reinforced soil retaining structures.
Suitable for a wide range of gravity and reinforced soil retaining wall applications, including:
Secura Grand combines speed of installation with a high-quality aesthetic finish, making it ideal for residential, commercial, and infrastructure projects.
Secura Grand is a high-performance, mortarless segmental retaining wall system developed for taller gravity and reinforced soil structures. The large interlocking concrete blocks enable fast, dry-build installation without the need for mortar, pins, or mechanical connectors.
Designed for strength, efficiency, and aesthetic appeal, Secura Grand is ideal for both gravity and reinforced soil applications on residential, commercial, and infrastructure projects. The system accommodates rapid construction while maintaining precise alignment and a clean, modern appearance.
Manufactured to the highest standards of dimensional accuracy and durability, Secura Grand blocks are CE-marked and compliant with BS EN 771-3. The system can be combined with geogrid reinforcement for greater retained heights or used as a standalone gravity solution for smaller walls.
Available in multiple blended colours that complement Tobermore paving and walling ranges, Secura Grand provides an attractive, long-lasting finish suitable for any landscape or structural setting.
Features and Benefits:
Color | Other Guidance for specification option:
|
Finish | Tumbled |
Material | Concrete |
Shape | Rectangle |
Length | 400 mm |
Width | 230 mm |
Height | 200 mm |
Uniclass | |
CAWS | D41/310 Drystack interlocking masonry |
Classification data | |
Standard | To BS EN 771-3:2011. |
Properties | |
Dimensions | 400 x 230 x 200 mm. |
Special units | |
Type of special unit | None. |
Dimensions of special units | 400 x 230 x 200 mm. |
Finish | |
Exposed faces | Aged finish. |
Colour | Bracken. Heather. Slate. |
Environmental rating | 3.49 Guidance for specification option: kgCo²e/m². |
Strength | >30 N/mm². |
Efflorescence | Minimum 12 hour vapour curing to reduce the possibility of efflorescence. |
EnergyUsed | 100% Renewable energy. |
WaterUsed | 100%. Guidance for specification option: From rainwater harvesting system and groundwater bore hole. |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Concrete |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Certified | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/unit) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 3.49 | |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Manufacturer guidanceNot less than 6%. |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
| - | 1 | |
| - | 1 |
