SeceuroFire 30, 60, 120, 240

Third party certifications:
  • QA Certificate

    Certificate type

SWS UK

Electrically operated, automatic, vertical fire-resistant shutter.

Jump to:
+44 (0)1524 772400 www.sws.co.uk
Application

For use as a standard shutter within openings e.g. in shopping centres, until required for automatic deployment.

Description

Electrically operated, automatic, vertical fire-resistant shutter, available in four different integrity ratings.

Designed to be a security barrier during normal use, and to be closed automatically during a test or emergency situation. In the event of receiving a fire alarm signal, the barrier will perform a powered descent to create a fire resistant barrier. In the event of power failure, the shutter will close using the battery back-up feature.

Features and benefits:

  • Suitable for both face or reveal installations.
  • Provides easy access to the end plate fixtures, with easy and quick attachment.
  • Wide variety of sizes available.
  • Fast and easy attachment of the axle, with two shelf brackets and easy access bolts.
  • Non-welded assembly design allows post order alteration if required.
  • Range of hood configurations available.
  • Fixing kits are available if required - consult manufacturer for details.
  • Guide offsets are symmetrical.
  • Can be RAL or BS coated.
  • Manufactured in the UK.
  • Tested to EN 16034: 2014, and approved by Warrington Fire.
  • 12-month guarantee.

Consult manufacturer for details of maintenance recommendations.

Application:

For use as a standard shutter within openings e.g. in shopping centres, until required for automatic deployment.

General information
Finish

Galvanized

Standard.

Powder-coated

Insert RAL or BS colour requirement.

Uniclass 2015
Fire-resisting roller shutters (Pr_30_59_84_30)Primary
Specification data - Fire-resisting roller shutters
Product Reference

Seceurofire 30

30 minutes integrity performance.

Seceurofire 60

60 minutes integrity performance.

Seceurofire 120

120 minutes integrity performance.

Seceurofire 240

240 minutes integrity performance.

Opening sizes

660–5500 x 660–5500 mm (w x h), insert requirements.

Arrangement

Face fitted

Reveal fixed

Shutter curtain

75 mm scrolled slats

Control

FC Control Panel

Includes alarm input, emergency override, audio visual output and 24 V battery back-up.

FC+ Control Pane

As FC, with split drop curtain and safety device inputs.

SFP Control Panel and Key Switch

With Power Manager battery back-up and interface internally fitted for NRG panel.

SFP+ Control Panel and Key Switch

As SFP, with additional override functionality.

SF1 Control Panel and Key Switch

With Power Manager battery back-up and interface internally fitted for panel.

ProMate and Key Switch

With Power Manager battery back-up.

Finish

Galvanized

Standard.

Powder-coated

Insert RAL or BS colour requirement.

Accessories/ Other requirements

Not required

Audio visual warning device

Only available for use with control panel.

Emergency retract switch

FS control repeater panel

Only available for use with control panel.

Key switch

Only available for use with control panel.

Photocell

Only available for use with control panel.

Smoke detector

Only available for use with control panel.

Stop button

Only available for use with control panel.

Standard product features

Components:

  • Box assembly: Galvanized steel sleeved sections (to allow for expansion starting from 250 mm endplate, depending on shutter height and component integrity requirements).
  • Guide rails: 3 mm thick and 65, 75 or 100 mm deep, depending upon shutter width mounted on steel angles for fixing.
  • Bottom rail: T-Sectioned steel bottom slat, 49 x 74 mm (h x d).
  • Axles: Round steel barrel (differs depending on product size).
  • Motor: 240 V AC tubular motor, supplied as standard with a 2.5 m, four core cable.

Product Options

Opening sizes:

Sizes can vary according to integrity rating. Larger sizes require an axle support cradle, consult manufacturer for details.

Finish:

Applies to box, curtain, guide rails and bottom rail.

Third party certifications
  • Warrington Fire : Assessment report 416153 (BS EN 13241: 2003+A2: 2016), 415114 (EN 16034: 2014), EXAP report 415113
