Screed Sheet
Application

Suitable for interior use, including schools, hospitals, museums, offices and other places of work.

Description

Smooth, non-slip, resilient rubber flooring sheet with hand finished screed effect and PRO surface treatment.


Features and benefits:

  • The PRO surface treatment has UV linked polymeric coating technology. The coating finish protects the surface, improves performance and reduces the need for cleaning and maintenance.
  • Available as X-Elastic acoustic flooring (specified separately).
  • Also available in tile format (specified separately).
  • Smooth, non-slip resilient rubber flooring tile with marbled effect and PRO surface treatment.

General information

Color

Six options.

-

Finish

Smooth

Material

Rubber

Shape

Rectangle

Size

3 x 1900 x 10 000 mm

Uniclass 2015

Pr_35_57_71_80 Smooth rubber sheetsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Specification data - Smooth rubber sheets Enhanced data

Standard

To BS EN 1817 and BS EN 14041.

Use class

To BS EN ISO 10874 class 23/ 34/ 43.

Width

1900 mm.

Length: 10 m.

Thickness

3 mm.

Colour and pattern

S1 Ivory.

S2 Antique.

S3 Greige.

S4 Haze.

S5 Cement.

S6 Charcoal.

Product Reference

Screed Sheet

Slip Potential - Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

Slip resistance to EN 13893 DS.

Weight

5.2 kg/m².

Hardness (to ISO 7619)

Shore 88.

Residual indentation (to EN/ISO 24343-1 (EN 433))

0.04 mm.

Abrasion resistance (to ISO 4649)

165 mm³.

Dimensional stability (to EN/ISO 23999 (EN 434))

±0.30%.

Flexibility (to EN/ISO 24344 Met. A Ø 20 mm (EN 435))

Complies.

Colour fastness to artificial light (to ISO 105-B02 Met. 3)

Complies.

Cigarette burn (to EN 1399)

Complies.

Fire behaviour (to EN 13501-1)

Class Cfl–s1.

Toxicity of decomposition gases (to DIN 53436 at 350°C)

Not toxic.

Resistance to stains (to EN/ISO 26987 (EN 423))

Resistant.

Depending on concentration and time of contact: for specific agent contact manufacturer.

Ramp slip resistance (to DIN 51130)

R9.

Thermal resistance (to EN 12667)

0.020 m²K/W.

Thermal conductivity (to EN 12667)

0.15 W/m·K.

Electrical resistance (to EN 1081 Met. A)

>10^10 ohms.

Electrostatic charge (to EN 1815)

≤2 kV (antistatic).

Reduction of sound due to treading (to ISO 10140-3)

Up to 10 dB.

Castor chairs (to EN 425)

Suitable for W castors.

VOC emissions (CA Section 01350)

Complies.

VOC emissions (AgBB)

Complies.

Digital objects
Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
Literature
Third party certifications

Additional certifications:

  • Émissions dans l’air intérieur: A+
  • UL: GREENGUARD - Certified
  • UL: GREENGUARD Gold - Certified
  • Blue Angel: RAL UZ 120 - Certified
