Screed Sheet
QA Certificate
Certificate type
Smooth, non-slip, resilient rubber flooring sheet with marbled effect and PRO surface treatment.
Suitable for interior use, including schools, hospitals, museums, offices and other places of work. Classification (to EN ISO 10874 (EN 685)): 23 (Residential); 34 (Commercial); 43 (Industrial).
Smooth, non-slip, resilient rubber flooring sheet with hand finished screed effect and PRO surface treatment.
Features and benefits:
- The PRO surface treatment has UV linked polymeric coating technology. The coating finish protects the surface, improves performance and reduces the need for cleaning and maintenance.
- Available as X-Elastic acoustic flooring (specified separately).
- Also available in tile format (specified separately).
Application:
Suitable for interior use, including schools, hospitals, museums, offices and other places of work. Classification (to EN ISO 10874 (EN 685)): 23 (Residential); 34 (Commercial); 43 (Industrial).
Color | S1 Ivory S2 Antique S3 Greige S4 Haze S6 Charcoal S5 Cement |
Features | Smooth, non-slip resilient rubber flooring tile with marbled effect and PRO surface treatment |
Finish | Smooth |
Material | Rubber |
Shape | Rectangle |
Size | 3 x 1900 x 10 000 mm |
Uniclass 2015 | |
CAWS | M50/150 Sheeting M50/20 Sheeting |
Product Reference | Screed Sheet |
Standard | To BS EN 1817 and BS EN 14041 |
Use class | To BS EN ISO 10874 class 23/ 34/ 43 |
Slip potential | - |
Slip Potential - Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum) | DS |
Width | 1900 mmLength: 10 m. |
Thickness | 3 mm |
Colour and pattern | S1 IvoryS2 AntiqueS3 GreigeS4 HazeS5 CementS6 Charcoal |
Weight | 5.2 kg/m² |
Technical characteristics to EN 12199 | - |
Hardness (to ISO 7619) | Shore 88 |
Residual indentation (to EN/ISO 24343-1 (EN 433)) | 0.04 mm |
Abrasion resistance (to ISO 4649) | 165 mm³ |
Dimensional stability (to EN/ISO 23999 (EN 434)) | ±0.30% |
Flexibility (to EN/ISO 24344 Met. A Ø 20 mm (EN 435)) | Comply |
Colour fastness to artificial light (to ISO 105-B02 Met. 3) | Comply |
Cigarette burn (to EN 1399) | Comply |
Technical characteristics to EN 14041 | - |
Fire behaviour (to EN 13501-1) | Class Cfl–s1 |
Technical characteristics, other | - |
Toxicity of decomposition gases (to DIN 53436 at 350°C) | Not toxic |
Resistance to stains (to EN/ISO 26987 (EN 423)) | ResistantDepending on concentration and time of contact: for specific agent contact manufacturer. |
Ramp slip resistance (to DIN 51130) | R9 |
Thermal resistance (to EN 12667) | 0.020 m²K/W |
Thermal conductivity (to EN 12667) | 0.15 W/m·K |
Electrical resistance (to EN 1081 Met. A) | >10^10 ohms |
Electrostatic charge (to EN 1815) | ≤2 kV (antistatic) |
Reduction of sound due to treading (to ISO 10140-3) | Up to 10 dB |
Castor chairs (to EN 425) | Suitable for W castors |
VOC emissions (CA Section 01350) | Comply |
VOC emissions (AgBB) | Comply |
Standard product features | Colour: Six options. Features: Smooth, non-slip resilient rubber flooring sheet with hand finished screed effect and PRO surface treatment. Finish: Smooth. Material: Rubber. Shape: Rectangular. Size: 3 x 1900 x 10 000 mm. |
| Platform | Compatible | Version | Certified to |
|---|---|---|---|
 IFC | - | 1 | 2.1 |
 Revit | - | 1 | 2.1 |
QA Certificate
Eurofins: Indoor Air Comfort GOLD - Certified
Additional certifications:
- Émissions dans l’air intérieur: A+
- UL: GREENGUARD - Certified
- UL: GREENGUARD Gold - Certified
- Blue Angel: RAL UZ 120 - Certified
