Schlüter®-BARA-ESOT - Skirting Support Profile

Verified by manufacturer 5 months ago

Schlüter-Systems Ltd

A stainless steel angular support profile for bonding skirting tiles to non-load-bearing substrates.

Jump to:
+44 (0)1530 813396 Website

Application

For bonding skirting tiles to non-load-bearing substrates, including zinc-flashing or bituminous waterproofing layers which are used at wall/ floor transitions on balconies and terraces.

Description

A stainless steel angular support profile for bonding skirting tiles to non-load-bearing substrates, including zinc-flashing or bituminous waterproofing layers which are used at wall/floor transitions on balconies and terraces. Installation is preferred by Schlüter-Systems trained installers.


Features and benefits:

  • Both legs of the profile are perforated. In addition, the vertical leg includes spacer deflections.
  • Profiles require no special or preventative maintenance.

General information

Color

Silver

Finish

Natural

Material

Stainless steel

Guidance for specification option:

V2A = 1.4301.

Shape

Other

Guidance for specification option:

L shaped

Length

2500 mm

Width

60 mm

Height

60 mm

110 mm

Warranty description

Five year

Uniclass

Pr_35_90_22_52 Metal edgingsPrimary

CAWS

M40/10 Natural stone covering to

M40/110 Tiling to

M40/115 Natural stone covering to

M40/120 Mosaic to

M40/5 Tiling to

Specification data - Metal edgings

Material

Stainless steel.

Guidance for specification option:

V2A = 1.4301.

0.8 mm thick.

Edging

-

Form

Straight.

Guidance for specification option:

 Both legs of the profile are perforated. In addition the vertical leg includes spacer deflections.

Length (minimum)

2500 mm.

Guidance for specification option:

Standard unit.

Other.

Guidance for specification option:

Insert requirements (standard unit length: 2500 mm)..

Size

60 x 60 mm.

110 x 60 mm.

Colour

Silver (dull finish).

Fixings

Adhesive fixed.

Sustainability data

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

Germany

Recyclability

-

Manufacturer guidance

Product can be recycled where local facilities exist.
