SCB (Sleeved Cavity Barrier)
Verified by manufacturer 4 months ago
EN 13501-2
Certificate type
Sleeved cavity barrier for masonry, timber and steel-framed constructions
Application
ROCKWOOL SCB is suitable for cavities between a masonry outer leaf and the following substrate types:
- Masonry.
- Timber frame faced with OSB.
- Steel frame faced with cement particle board.
Description
ROCKWOOL SCB consists of stone wool insulation strips encapsulated in a protective polythene sleeve. Fitted under compression, the product acts to inhibit the passage of smoke and fire within masonry, timber and steel frame constructions.
General information
Finish | Film |
Material | Stone wool |
Shape | Rectangle |
Length | 1200 mm |
Width | 110 mm 200 mm |
Height | Bespoke |
Uniclass | |
CAWS | P10/420 Sleeved mineral wool small cavity barriers P10/70 Sleeved small cavity barriers |
Specification data - Sleeved mineral wool cavity barriers
Cavity barriers | |
Sleeves | Polythene sleeve. |
Size | 110 x 1200 mm.200 x 1200 mm. |
Residual cavity width | Manufacturer guidanceTo suit cavity 50–290 mm. |
Fire performance | Up to E120 (EI45), depending on application. |
Thickness: | Manufacturer guidanceThicknesses available: 65–300 mm. Insert requirement. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Stone wool |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
