Application

For private and commercial use indoors with a direct contact with tap and cleaning water.

Description

Sanbath Cube stands out through its clear lines and sleek elegance. Sanbath Wave is setting new trends in the wellness bathrooms with its wavy forms.

All elements from the Sanbath series are ready to assemble and have the same waterproof core as the wedi building boards. After setting up and connecting the elements, they can be tiled straight away.

Features and benefits:

  • Supplied with one hansgrohe iBox (with prefabricated piping for a head shower).
  • Suitable for direct tiling.
  • Waterproof.
  • Heat insulating.
  • Stable and lightweight.
  • CO2-foamed, extruded polystyrene rigid foam with closed cell structure and flame-retardant additive. The polystyrene rigid foam is hydrochlorofluorocarbon (HCFC) and chlorofluorocarbon (CFC) free.

Applications:

For private and commercial use indoors with a direct contact with tap and cleaning water.

General information
Specification data - Shower enclosures
Product Reference

Sanbath Cube Shower Unit

2200 x 400 x 850 mm.

Sanbath Wave Shower Unit

2500 x 1010.5 x 400 mm.

Accessories

None

Building board

Various options available, consult literature and insert requirements.

Fundo Primo

Fundo Primo Easy Set

Point drainage

Various options available, consult literature and insert requirements.

wedi 320 tile adhesive

wedi 610 – adhesive sealant

wedi Fundo sealing set

wedi tools joint reinforcement tape

wedi tools sealing tape

Standard product features

Technical characteristics:

Fire behaviour (EN 13501): Class E.

– Raw foam building board systems:

  • Type: Extruded polystyrene (XPS) rigid form core.
  • Long-term compressive strength (50 years) ≤2% compression (EN 1606): 0.08 N/mm².
  • Compressive resistance or compressive strength at 10% compression (EN 826): 0.25 N/mm².
  • Associated module of elasticity (EN 826): 10–18 N/mm².
  • Thermal conductivity (EN 13164): 0.033 W/mK.
  • Tensile strength (EN 1607): 0.45 N/mm².
  • Shearing resistance (EN 12090): 0.2 N/mm².
  • Shear modulus (EN 12090): 7 N/mm².
  • Bulk density (EN 1602): 32 kg/m³.
  • Resistance to water vapour diffusion (EN 12086): 100 µ.
  • Water absorption under long-term immersion (EN 12087): ≤1.5% by volume.
  • Capillary action: 0.
  • Linear coefficient of thermal expansion: 0.07 mm/mK.
  • Temperature limits: -50 to +75°C.
  • Fire behaviour (EN 13501): Class E.
  • Carbon dioxide propellant (Global Warming Potential, GWP) value: 1.
