Application

Ideal for entrances or areas with heightened security requirements, for example jewellery outlets, retail stores, markets, shopping centres, banks, savings companies, post offices, sensitive industrial zones such as laboratories, R&D or IT areas, chemists shops and drug stores in hospitals.

Description

The record Safecord is equipped with the following features to meet security requirements:

  • Record MPV multipoint locking.
  • Special laminated safety glass.
  • Heavy-duty running gear.
  • Reinforced door construction.
  • Extended floor guides.

Integrating the record Safecord into a building control system can further enhance the level of security. Any tampering with the door immediately triggers an alarm to alert security personnel. As the Safecord door effectively resists would-be burglars, security staff have sufficient time to take the necessary action.

Applications:

Ideal for entrances or areas with heightened security requirements, for example jewellery outlets, retail stores, markets, shopping centres, banks, savings companies, post offices, sensitive industrial zones such as laboratories, R&D or IT areas, chemists shops and drug stores in hospitals.

Benefits:

Presents an invisible, effective barrier to burglars, which can be an advantage in insurance issues tested in line with RC 2 norms and requirements.

General information
Specification data
Product Reference

Safecord

Type

D-STA

Two leaves.

E-STA

One leaf.

Opening width

800–3000 mm. Insert requirements.

Accessories

A wide range available; insert requirements from 'Options' below.

Standard product features

Clear height of passage:

3000 mm.

Door leaf weight (maximum):

E-STA: 1 x 150 kg.

D-STA: 2 x 120 kg.

DUO/ RED model:

  • E-STA: 1 x 150 kg.
  • D-STA: 2 x 150 kg.

Drive dimensions:

  • With side screen (d x h): 197 x 200 mm.
  • Without side screen (d x h): 160 x 200 mm.

Resistance class:

RC 2, certified by IFT Rosenheim.

Electrical connection:

230 V/ 50/ 60 Hz/ 100 W.

Product Options

Burglary/ safety protection:

  • P5A laminated safety glass in line with EN 356.
  • Modified running gear protected against lifting.
  • Structural reinforcements on side screens, door leaves and closing edges.
  • MPV multi-point locking.
  • Floor rails made of stainless steel.
  • Continuous floor guide.
