Name: ROOFBOX® M Bespoke - Roof Service Penetrations Unit
Brand: Nicholson STS Ltd
SKU: gAvj5vy1P5ec9dmwnzHVd5

Color

Grey

Other

Guidance for specification option:

Insert reqirement.

Finish

Powder-coated

Material

Aluminium

Polyisocyanurate (PIR)

Manufacturer guidance

Frame components: 3.0 mm-thick 5251 grade aluminium as standard (3.0 mm-thick galvanized carbon steel may be required for longer spans; consult manufacturer for details).
Frame bolting: A2 stainless steel M10 bolts, nuts and washers.
Apron flashing: 1.0 mm-thick 5251 grade aluminium.
Vertical panels: 2.0 mm-thick 5251 grade aluminium, 50 mm-thick foil faced insulation, thermal transmittance 0.41 W/m²K.
Roof closure panels: 3.0 mm-thick 5251 grade aluminium; 50 mm-thick foil faced insulation. Thermal transmittance: 0.41 W/m²K.
Insulation in panels: 50 mm-thick foil faced polyisocyanurate (PIR) insulation 0.022 W/m·K providing an overall U-value of 0.41 W/m²K. Fire performance: Class 1 (BS 476, Part 7), Euroclass F (BS EN 13501-1). Further insulation options are available to provide enhanced U-values and fire ratings; consult manufacturer's technical department for further information.
Compressible foam seal: Impregnated polyurethane (PUR) flexible foam tape with fire resistant polymeric impregnant.
Flashings: 2.0 mm-thick 1050 grade aluminium.
Panel and flashing fixing screws: A2 stainless steel with self-drilling tip, ultra-low-profile head with T25 drive, aluminium/ ethylene propylene diene monomer (EPDM) bonded sealing washers.

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

20 year

Guidance for specification option:

Subject to a successful warranty application at design stage and a post-installation inspection.

Uniclass

Pr_80_77_28_74 Roof penetration boxesPrimary

CAWS

Q37/130 Extensive green roof

Q37/120 Simple intensive green roof

Q37/110 Intensive green roof

J41/135 Single-layer reinforced bitumen membrane cold deck roof covering

J41/130 Built-up reinforced bitumen membrane cold deck roof covering

J41/125 Single-layer reinforced bitumen membrane inverted roof covering

J41/120 Built-up reinforced bitumen membrane inverted roof covering

J41/12 Reinforced bitumen membrane cold deck roof covering

J31/130 Inverted roof coating

J31/110 Cold deck roof coating

J31/12 Inverted roof coating

J31/5 Cold deck roof coating

Material

5251 grade aluminium.

Guidance for specification option:

Frame components: 3.0 mm-thick aluminium.
Frame bolting: A2 stainless steel M10 bolts, nuts and washers.
Vertical panels: 2.0 mm-thick aluminium
Roof closure panels: 3.0 mm-thick aluminium.
Compressible foam seal: Impregnated polyurethane (PUR) flexible foam tape with fire resistant polymeric impregnant.
Flashings: 2.0 mm-thick 1050 grade aluminium.
Panel and flashing fixing screws: A2 stainless steel with self-drilling tip, ultra-low-profile head with T25 drive, aluminium/ ethylene propylene diene monomer (EPDM) bonded sealing washers.

Manufacturer guidance

See Insulation property for further details.

Insulation

50 mm-thick foil faced polyisocyanurate (PIR).

Guidance for specification option:

Included in vertical and roof closure panels.
0.022 W/m·K providing an overall U-value of 0.41 W/m²K.
Fire performance: Class 1 (BS 476, Part 7), Euroclass F (BS EN 13501-1).

Manufacturer guidance

Further insulation options are available to provide enhanced U-values and fire ratings; consult manufacturer's technical department for further information.

Factory finish

Coating

Polyester powder-coated.

Colour

RAL 7047.

Guidance for specification option:

Standard.

RAL, bespoke.

Guidance for specification option:

Insert requirement.

Film thickness (minimum)

Manufacturer's standard.

Configuration

Manufacturer guidance

Include information on the configuration of the box, e.g. side entry, louvres, opening lid, side access panels, etc.

Refer to drawings or proprietary reference, where appropriate.

Weathering accessories specified separately as required.

Where the standard configurations in the Roofbox M range are not suitable, a bespoke solution can be manufactured to suit larger or different size or shaped riser openings and in taller heights. These roof cabinets can also be configured to interface with parapet walls, corners and lift overruns. Contact manufacturer with detailed riser opening requirements.

When mounted on a concrete kerb upstand, an aluminium skirt flashing detail can be utilized at the base of the unit, to weather over the insulation on the face of a concrete kerb.

Dimensions

Roof opening

Manufacturer guidance

Insert requirements.

Services requirements

Manufacturer guidance

Insert requirements.

Integral kerb

Roofbox K Bespoke.

Guidance for specification option:

Specified separately.

Site formed.

Cabinet

Manufacturer guidance

Insert requirements.

Accessories

None.

Generic.

Guidance for specification option:

Service flashings and weathering items to suit MEP arrangements. Insert requirements.

Flashings.

Guidance for specification option:

Insert requirements.

Universal flashing kit available for square and rectangular ducts.
Universal flashing kit available for square and rectangular ducts.

Ventilation louvre(s).

Guidance for specification option:

Insert requirements.

Available in a range of sizes; consult manufacturer's literature for details, and for maximum allowable louvre dimensions for each cabinet.
Polyester powder-coated and colour matched to the cabinet unless specified otherwise (RAL 7047 as standard).

Weathering hood(s).

Guidance for specification option:

Insert requirements.

Polyester powder-coated to RAL 7047 as standard, and can be colour matched to the cabinet.

H30: Internal width: 300 mm.
H40: Internal width: 400 mm.
H70: Internal width: 700 mm.
H90: Internal width: 900 mm.

Access panel(s).

Guidance for specification option:

Insert requirements.

Available in a range of sizes; consult manufacturer's literature for details.
Polyester powder-coated to RAL 7047 as standard, and can be colour matched to the cabinet.

Verification

Submittals

Manufacturer guidance

See generic guidance and insert requirements.

Timing

Manufacturer guidance

See generic guidance and insert requirements.

Standards

To BS 476, Part 7, BS EN 13501-1.

Fire classification

Euroclass F.

Contains Red List materials

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Aluminium

Polyisocyanurate (PIR)

Manufacturer guidance

Frame components: 3.0 mm-thick 5251 grade aluminium as standard (3.0 mm-thick galvanized carbon steel may be required for longer spans; consult manufacturer for details).
Frame bolting: A2 stainless steel M10 bolts, nuts and washers.
Apron flashing: 1.0 mm-thick 5251 grade aluminium.
Vertical panels: 2.0 mm-thick 5251 grade aluminium, 50 mm-thick foil faced insulation, thermal transmittance 0.41 W/m²K.
Roof closure panels: 3.0 mm-thick 5251 grade aluminium; 50 mm-thick foil faced insulation. Thermal transmittance: 0.41 W/m²K.
Insulation in panels: 50 mm-thick foil faced polyisocyanurate (PIR) insulation 0.022 W/m·K providing an overall U-value of 0.41 W/m²K. Fire performance: Class 1 (BS 476, Part 7), Euroclass F (BS EN 13501-1). Further insulation options are available to provide enhanced U-values and fire ratings; consult manufacturer's technical department for further information.
Compressible foam seal: Impregnated polyurethane (PUR) flexible foam tape with fire resistant polymeric impregnant.
Flashings: 2.0 mm-thick 1050 grade aluminium.
Panel and flashing fixing screws: A2 stainless steel with self-drilling tip, ultra-low-profile head with T25 drive, aluminium/ ethylene propylene diene monomer (EPDM) bonded sealing washers.

Recyclability

Recyclable at end of life

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

50 %

Expected Life

30 year

Platform

Compatible

Version

Revit

IFC
