Roma-3 Fencing - Steel grating protective barrier fence

Name: Roma-3 Fencing - Steel grating protective barrier fence
Brand: Lang+Fulton
SKU: cDEyYKjvn58yfhRrBPzARQ

Verified by manufacturer 1 month ago

Lang+Fulton

A secure steel grating fence with rectangular apertures.

Jump to:

+44 (0)131 441 1255 Website

Application

Suitable for schools and colleges, commercial premises and municipal areas.

Description

Roma-3 has a rectangular aperture and is the most widely specified type of grating fence for schools, colleges, commercial premises and municipal areas. It is made with a 25 x 3 mm flat bar which provides excellent rigidity and durability. There are three versions of the Roma fence.

Features and benefits:

Mesh size: 62 x 132 mm; Vertical flat bars 25 x 3 mm; Horizontal round bars: 5 mm diameter.
Single leaf, double leaf, pivot, cantilevered or sliding gates are made to match with Roma infill panels.
Panels and posts can be supplied galvanized only or galvanized and powder coated to any RAL colour.
Bespoke designs: The integrity of the grating material allows it to be cut, shaped or rolled to create customized fencing which include curved top, waved top or radiused panels.
Incorporates ornamental motifs and laser cut panels.
Other alternative designs include decorative rails, handrails and feature posts with optional finials in steel or wood.
Available in alternative lengths and style of posts for ground fixing, anchoring within wall pockets, base plates for fixing to a concrete foundation and off-set over top of wall.
Non-standard special panel widths can be reduced on site to suit ends of fence runs, and fixed using hidden sleeves fitted to the rails.
Grating fences are supplied in accordance with BS 1722-14.

General information

Color	Grey Beige Black Blue Bronze Brown Copper Gold Green Red Silver White Other Yellow Show more
Finish	Galvanized Guidance for specification option: Hot-dipped to BS EN ISO 1461. Powder-coated Guidance for specification option: Hot-dip galvanized and polyester powder coated to BS EN ISO 1461 and BS 1722–16.
Material	Steel
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke

Uniclass	Ss_25_14_61_51 Metal mesh panel fencing systemsPrimary Ss_25_14_61_62 Post and panel fencing systems
CAWS	Q40/27 Open mesh steel panel general purpose fencing Q40/30 Proprietary fencing Q40/430 Proprietary fencing Q40/126 Open mesh steel panel security fencing Q40/125 Open mesh steel panel general purpose fencing

Product range	Fencing

Specification data - Metal mesh panel fencing systems

Standard	To BS 1722-14.
Posts	Mild steel S235JR.
Post foundations	Ground fixing (concrete mix). Base plates for fixing to a concrete foundation. Off-set over top of wall. Anchoring within wall pockets. Manufacturer guidance Alternative lengths and style of post, dependent on fixing.
Rails	Not required. Hand rail.
Panels	Vertical flat bars and horizontal round bars, framed top and bottom with flat bars, mild steel S235JR.
Fence topping	Not required. Curved top. Waved top. Decorative rail. Manufacturer guidance Framed top and bottom with flat bars.
System accessories	Not required. Entry/ exit controls. Ornamental motifs. Laser cut panels. Wood finials. Steel finials.

Panel heights	930 mm. Guidance for specification option: Nominal height: 1.0 m (framed and fixed). 1194 mm. Guidance for specification option: Nominal height: 1.25 m (framed and fixed). 1326 mm. Guidance for specification option: Nominal height: 1.4 m (framed and fixed). 1458 mm. Guidance for specification option: Nominal height: 1.5 m (framed and fixed). 1722 mm. Guidance for specification option: Nominal height: 1.8 m (framed and fixed). 1986 mm. Guidance for specification option: Nominal height: 2.0 m (framed and fixed). 2118 mm. Guidance for specification option: Nominal height: 2.2 m (framed and fixed). 2382 mm. Guidance for specification option: Nominal height: 2.4 m (framed and fixed). 2646 mm. Guidance for specification option: Nominal height: 2.7 m (framed and fixed). 2910 mm. Guidance for specification option: Nominal height: 3.0 m (framed and fixed). Show more
Width	1992 mm. Guidance for specification option: Achieves a nominal width of 2.0 m when framed and fixed. Manufacturer undertaking: Non-standard widths are fabricated to custom size following a site survey, or cut on site and fixed to posts with adjustable lug. Manufacturer guidance Panel.
Straight section	50 x 30 mm RHS. Guidance for specification option: For panel heights: 930, 1194, 1326 or 1458 mm. 60 x 40 mm RHS. Guidance for specification option: For panel height: 1722 mm. 80 x 40 mm RHS. Guidance for specification option: For panel heights: 1986, 2118, 2382 or 2646 mm. 100 x 50 mm RHS. Guidance for specification option: For panel height: 2910 mm. 60 x 7 mm flat bar. Guidance for specification option: For panel heights: 930, 1194, 1326, 1458 or 1722 mm. 80 x 8 mm flat bar. Guidance for specification option: For panel heights: 1986, 2118 or 2382 mm. 50 mm diameter tubular. Guidance for specification option: For panel heights: 930, 1194, 1326, 1458 mm. 76 mm diameter tubular. Guidance for specification option: For panel heights: 1722, 1986, 2118 or 2382 mm. 89 mm diameter tubular. Guidance for specification option: For panel height: 2646 mm. 114 mm diameter tubular. Guidance for specification option: For panel height: 2910 mm. Show more Manufacturer guidance RHS: Rectangular hollow sections.
Corners	60 x 60 mm RSA. Guidance for specification option: For panel heights: 930, 1194, 1326, 1458 or 1722 mm. 80 x 80 mm RSA. Guidance for specification option: For panel heights: 1986, 2118, 2382 or 2646 mm. 100 x 100 mm RSA. Guidance for specification option: For panel height: 2910 mm. 60 x 60 mm SHS. Guidance for specification option: For panel heights: 930, 1194, 1326, 1458 or 1722 mm. 80 x 80 mm SHS. Guidance for specification option: For panel heights: 1986, 2118, 2382 or 2646mm. 100 x 100 mm SHS. Guidance for specification option: For panel height: 2910 mm. Two flat bar posts. Guidance for specification option: For corners that are not 90 degrees. Show more Manufacturer guidance RHA: Rolled steel angle. SHS: Square hollow sections.
Finish:	Hot-dip galvanized. Guidance for specification option: To BS EN ISO 1461. Hot-dip galvanized and polyester powder coated, RAL. Guidance for specification option: Insert colour requirement. To BS EN ISO 1461 and polyester powder coated to BS EN 1722-16 in any RAL colour. Polyester powder coating is a multi-stage process which applies thermo-setting resins, producing a superior finish to painting.
Orientation	Round bars set to the inside of the enclosed area.
Fixing	Fixing lugs for a bolted panel-to post-connection. Guidance for specification option: This framing bar is bent over at the ends to form fixing lugs for a bolted panel-to post-connection. Fence heights of 1986 mm and above have an additional intermediate fixing.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	United Kingdom
Material	Steel
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	1.42 kg CO₂ eq/kg Self declared
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	56 %
