Rockfon® MediCare® Block - High Performance Ceiling Tile

Verified by manufacturer 2 months ago

MediCare Block A24 System T24 A/EECR - 1200 x 600 x 25 mm

Rockfon Variant:
Third party certifications:
  • EPD

    EPD

    Certificate type

High performance ceiling tile for use in high-risk, pressurized healthcare environments (HTM 60 compliant).

Jump to:
BOS
+44 (0)208 2227457 Website

Application

Suitable for use in high risk, pressurized healthcare environments where high cleanability is required, including:

  • Emergency rooms;
  • Washing facilities;
  • Intensive care;
  • Operating theatres (client approval required).


Consult manufacturer for details on recommended installation systems.

Description

Stone wool tile encased within an airtight and watertight inert film.


Features and benefits:

  • Class B sound absorption and B-s1, d0 fire safety.
  • The high performance inert film provides enhanced durability and water-repellence.
  • Hygienic; stone wool provides no sustenance to micro-organisms. This product adheres to microbiological class M1, fulfilling the requirements of Zone 4 (as defined by defined by NF S 90-351: 2013).
  • Easy to clean; can be cleaned with vacuum, damp cloth, and dry steam cleaning.
  • Resistant to disinfection using Hydrogen Peroxide Vapour, with no impact on aeration time.
  • Very good cleanability properties for most stringent cleaning methods.
  • Chemical resistance classification of ‘Excellent’ with a range of detergents and disinfectants – consult manufacturer for details.
  • Does not contribute to the growth of MRSA (ISO Class 2).
  • Compliant to HTM 60.
  • Other configurations may be available – consult manufacturer for details.


Humidity resistance and dimensional stability:

  • Dimensionally stable, even at humidity levels of up to 100% RH.
  • No visible deflection in high humidity.


Light reflection:

74%.


Demounting:

Rockfon tiles with A edges can be demounted.


Air pressure:

Due to its high performance film, combined with HDC2 clips (8 clips per 600 x 600 mm tile), it achieves an air leakage rate of less than 0.5 m³/h/m²/Pa under a pressure range of 5 to 40 Pa.


Emissions:

Awarded the Finnish M1 emission classification for building materials and the Danish Indoor Climate Label for low VOC emission products.


Compatible edges, grids and systems:

A24: Use with Chicago Metallic T24 2890 Click Grid to create Rockfon® System T24 A™ or Chicago Metallic T24 D2890 Click Grid to create Rockfon® System T24 A ECR™.


Cleaning:

  • Vacuum: The surface can be vacuum cleaned with a soft brush attachment.
  • Damp cloth: The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine (this may render the surface slightly shinier, so a thorough clean is recommended).

General information

Color

White

Finish

Film

Material

Stonewool

Shape

Rectangle

Square

Length

600 mm

1200 mm

Width

600 mm

Height

25 mm

Uniclass

Pr_35_93_13_80 Sound attenuator infill unitsPrimary
Ss_30_25_22_51 Modular suspended ceiling systems

CAWS

K40/115 Unit/ modular suspended ceiling system

K40/10 Unit/ modular suspended ceilings

K40/265 Infill units

Product range

Modular ceiling tiles

Specification data - Sound attenuator infill units

Form

Infill unit.

Rigidity

Rigid.

Application

Ceiling mounting.

Material

Stone wool.

Acoustic performance

-

Purpose

Absorber.

Sound absorption

Class B (to ISO 11654: 0.85 αw).

Fire performance

-

Reaction to fire

Class B-s1, d0 (to BS EN 13501-1).

Dimensions

-

Size (length x width)

1200 x 600 mm.

Thickness (overall)

25 mm.

Profile

Geometric profile.

Edges

A24.

Finish

Visible side: micro-textured, white painted, water repellent fleece; rear side: airtight, high performance membrane.

Certification

Cradle to Cradle Certified® Silver and Bronze.

Guidance for specification option:

Depending on product type.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Poland

Material

Stonewool

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

64 %

Third party certifications

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

4

IFC
-

4

Third party certifications

EPD

EPD

EPD Rockfon Medicare
