Rockfon Eclipse® wall panel (Square)

Name: Rockfon Eclipse® wall panel (Square)
Brand: vCSMA7AsRphSAo7cnDya2h
SKU: gwJk79mm6F96HKbPkTANQc

Aesthetic, frameless acoustic wall panel suitable for offices, reception areas etc. where extra sound absorption combined with good design is required

Jump to:

+44 (0)208 2227457 www.rockfon.co.uk

Application

Suitable for use in areas where extra sound absorption and good design are required, including the following:

Offices.

Reception areas.

Leisure.

Retail.

To be installed using the Rockfon® System Eclipse Wall™ installation system. Not suitable for use in swimming pools or outdoors – consult manufacturer for details.

Description

Stone wool frameless acoustic wall panel.

Features and benefits:

Class A sound absorption and Class A1 fire safety.

Aesthetically pleasing and attractive to the visible side, with a smooth, deep matt fleece.

Offers high sound absorption, light reflection and light diffusion.

Anti-static, which helps to extend the product lifetime.

Enhanced durability and dirt resistance.

Available in a variety of shaped formats and an unlimited colour range using NCS.

Easy to clean with a damp cloth or vacuum cleaner.

Quick and easy to install with the included wall fixing kit, which allows for the panel to be installed at different distances from the wall, creating interesting patterns.

Hygienic; stone wool provides no sustenance to micro-organisms.

Includes durable, painted edges.

Can be fully recycled.

Application:

Suitable for use in areas where extra sound absorption and good design are required, including the following:

Offices.

Reception areas.

Leisure.

Retail.

To be installed using the Rockfon® System Eclipse Wall™ installation system. Not suitable for use in swimming pools or outdoors – consult manufacturer for details.

General information

Finish	Smooth colour, matt fleece
Color	White
Material	Stone Wool
Size	1160 x 1160 x 40 mm
Uniclass 2015	Pr_35_93_13_80 Sound attenuator infill unitsPrimary
CAWS	K13/170 Acoustic panel lining

Specification data - Sound attenuator infill units

Product Reference	Rockfon Eclipse® Wall Panel
Module type	Circle 800 mm or 1160 mm diameter. Insert requirement. Freeform 1760 x 1160 mm. Hexagon 800 x 800 mm or 1160 x 1160 mm. Insert requirement. Ovoid 1760 x 1160 mm. Rectangle 1760 x 1160 mm or 2360 x 1160 mm. Insert requirement. Square 1160 x 1160 mm. Triangle 800 x 800 mm or 1160 x 1160 mm. Insert requirement.
Colour	Various available, consult manufacturer and insert requirements.
Edges	A

Standard product features

Thickness:

40 mm.

Surface finish:

Visible side: Smooth, deep matt, white painted fleece (other colours are available).

Rear side: Back fleece.

Sound absorption:

Class A.

Reaction to fire:

All module types (except 2360 x 1160 mm rectangle): Class A1.

2360 x 1160 mm rectangle: A2‑s1,d0.

Humidity and sag resistance:

Dimensionally stable, even at humidity levels of up to 90% RH.

Light reflection and light diffusion (white):

Reflection: Visible side: 87%; rear side: 79%.

Diffusion: >99%.

Wet scrub resistance:

To EN ISO 11998: 2007: Class 1.

Cleaning:

Vacuum: The surface can be vacuum cleaned with a soft brush attachment.

Damp cloth: The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine (this may render the surface slightly shinier, so a thorough clean is recommended).
