Riga Rhomb - Specialist Veneer Plywood

Name: Riga Rhomb - Specialist Veneer Plywood
Brand: Riga Wood
SKU: aAaVNSmnEUvxhBzHdDuWHS

Verified by manufacturer 2 days ago

6.5 mm

Riga Wood

Product certifications:

EPD
Certificate type
PEFC
Certificate type

A birch throughout plywood, overlaid with a hard wearing film with a rhomboid pattern surface, combining both functionality and a decorative visual appearance.

Jump to:

Request BIM

+44 (0)1959 565300 Website

Application

Road transport:

Light commercial vehicles;
Heavy commercial vehicles;
Buses.

Light building:

Stage systems and industrial flooring;
Joinery, furniture and shopfittings;
Outdoor solutions.

Description

Riga Rhomb is designed for technically demanding applications, where high wear resistance and good anti-slip properties are required.

Features and benefits:

Highly wear-resistant and anti-slip surface ensuring safety underfoot.
Weather-resistant gluing and water-resistant surface.
Excellent strength-to-weight ratio.
Durable and heavy-duty.
Surface is resistant to commonly used chemicals and surface impact, easy to clean.
Aesthetic and visually attractive.
Sustainable product with a long life span.

Further processing:

Riga Rhomb can be further processed according to customer's specification with cut-to-size, CNC, drilling, milling, jointing, edge machining, assembling in sets.

Surface properties:

The rhomboid pattern overlay improves panel resistance against mechanical damage and wear, whilst providing a decorative appearance. The surface resists abrasion, and commonly used chemicals, and is weather and moisture resistant. Rhomb Heavy with a wear resistant film significantly improves abrasion resistance. Riga Wood experts will advise the most appropriate overlay depending on the end use.

Overlaying

Overlaid with resin impregnated film, during the coating process a special rhomb pattern is hot-pressed onto the sheet surface. Depending on the application, films impregnated with unmodified or modified phenolic or melamine resins are applied.

Wear resistance

Rolling test (EN 1818) more than 10,000 cycles depending on the coating. Rolling wear is tested with a load of 300 kg.

Taber test (EN 438-2) for Riga Rhomb is up to 900 revolutions, for Riga Rhomb Heavy is up to 10,000 revolutions.

Slip resistance

Anti-slip resistance class R10 according to DIN 51130.

General information

Color	Black Blue Brown Green Grey Yellow Other Show more
Finish	Film
Material	Birch plywood
Shape	Rectangle Square
Length	1220 mm 1250 mm 1500 mm 1525 mm 2440 mm 2500 mm Bespoke Show more
Width	1220 mm 1250 mm 2440 mm 2500 mm 2745 mm 2750 mm 3000 mm 3050 mm Bespoke Show more
Height	6.5 mm 9 mm 12 mm 15 mm 18 mm 21 mm 24 mm 27 mm 30 mm 35 mm Show more

Uniclass	Pr_25_71_97_85 Specialist veneer plywoodsPrimary
CAWS	K11/37 Plywood flooring K11/315 Plywood flooring

Specification data - Specialist veneer plywoods

Classification data
Standards	BS EN 13986.
Third-party certification	EPD, FSC, PEFC.
Characteristics	Highly wear-resistant and anti-slip.
Material	-
Type	Birch plywood.
Face veneer	Eurpean birch, overlaid with resin impregnated film with rhomb pattern (Riga Rhomb). Eurpean birch, overlaid with resin impregnated film with rhomb pattern and wear resistant film (Riga Rhomb Heavy).
Balancing veneer	As per face veneer.
Bonding quality	To BS EN 314-2, Class 3. Guidance for specification option: As standard. To BS EN 314-2, Class 1 and BS 1203, H1. Manufacturer guidance Riga Wood birch plywood is glued with weather and boil-proof phenol formaldehyde or lignin phenol formaldehyde resin adhesive according to EN 314 Class 3 Exterior. Bonding with moisture resistant low emission melamine-urea formaldehyde resin according to EN 314 Class 1 and BS 1203 H1 possible.
VOC emissions	To EN 13986, Class E1 and complies with EPA TSCA Title VI and CARB Phase 2.
Number of plies	5.
Nominal thickness	6.5 mm.
Sheet size	1220 x 2440 mm. 1220 x 2500 mm. 1220 x 2745 mm. 1220 x 2750 mm. 1220 x 3000 mm. 1220 x 3050 mm. 1250 x 2440 mm. 1250 x 2500 mm. 1250 x 2745 mm. 1250 x 2750 mm. 1250 x 3000 mm. 1250 x 3050 mm. 1500 x 2440 mm. 1500 x 2500 mm. 1500 x 2745 mm. 1500 x 2750 mm. 1500 x 3000 mm. 1500 x 3050 mm. 1525 x 2440 mm. 1525 x 2500 mm. 1525 x 2745 mm. 1525 x 2750 mm. 1525 x 3000 mm. 1525 x 3050 mm. 2440 x 1220 mm. 2440 x 1250 mm. 2500 x 1220 mm. 2500 x 1250 mm. Bespoke.
Edges	Square.
Colour/ Finish	Dark brown. Light brown. Green. Black. Yellow. Silver grey. Honey. Light grey. Blue. Manufacturer guidance Film weights from 220 g/m2 to 660 g/m2. Based on phenolic resin: Dark brown, black, green, light brown, yellow, green. Based on melamine resin: Silver grey, honey, light grey, blue. The edges are sealed with colour matched moisture resistant paint. Other colours are available upon request.
Wear resistance	Rolling test to EN 1818: More than 10 000 cycles. Taber test to EN 438-2: Up to 900 revolutions (Riga Rhomb), up to 10 000 revolutions (Riga Rhomb Heavy).
Slip resistance	To DIN 51130, R10.

Sustainability data

Contains Red List materials	Yes Guidance for specification option: Formaldehyde.
Country of material origin	Europe Guidance for specification option: Grown, harvested and processed in the European Union.
Country of product manufacture	Europe Guidance for specification option: Grown, harvested and processed in the European Union.
Material	Birch plywood
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m³) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : -750
Recyclability	100% Guidance for specification option: Plywood can be reused endlessly depending on previous use conditions but it cannot be recycled as material for producing of new plywood.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
