RhinoGuard® Verso

Verified by manufacturer over a year ago

RhinoGuard® Verso 90° Block (15-30): VR-SE-00023

Marshalls Landscape Protection & Street Furniture Variant:

Precast concrete block modules to be used as standalone products or in conjunction with street furniture elements from the Verso street furniture range.

Jump to:
0370 600 2425 Website

Application

  • Landscape protection and street furniture.
  • Can be used with other street furniture elements from the Verso street furniture range.

Description

The RhinoGuard® Verso 90° Block, 600 Block, 1200 Block and 1800 Curve Block have been tested to the IWA14-1 standard and is capable of stopping a 1.5 tonne M1 vehicle, travelling at 30 mph. The RHINOGUARD® Verso 1200 Block and 1800 Curve Block are also capable of stopping a 7.2 tonne N2A vehicle, travelling at 30 mph.


The modules can be used with other street furniture elements from the Verso street furniture range, allowing for a mix of protective and non-protective seating and planter elements to be used in unison across a single project, as required.


The rated options within the RhinoGuard® Verso range allow for the protection of public spaces without compromising on the design or aesthetics.


Combining clean lines and an unobtrusive low height profile, the RhinoGuard® Verso Blocks can be used as a standalone product or combined with other elements from the Verso range to change the directional flow in a configuration whilst offering the capability of achieving a range of designs in order to suit the individual environment.


Manufactured in Britain using precast concrete, Verso is available in three timeless concrete colour options to complement any urban design. The longevity of the concrete material reduces maintenance costs and lowers carbon footprint over its life cycle.


Features benefits:

  • Impact tested to the IWA 14-1 standard.
  • Capable of withstanding a 1.5 tonne M1 vehicle travelling at 30 mph.
  • Helps create attractive schemes and avoids unnecessary fortification.
  • Also available as an unrated module.
  • Can be used in unison, across one project, mixed with rated and unrated modules or as a standalone block.
  • Once installed, protective and non protective units are indistinguishable.
  • Low level height.
  • Visually unobtrusive.
  • Available in three versatile concrete colour options.
  • The longevity of concrete means that Verso can be enjoyed for years to come.
  • Made in Britain.


General information

Color

Grey

Material

Precast concrete

Shape

Rectangle

Square

Other

Length

600 mm

900 mm

1200 mm

2093 mm

Width

600 mm

797 mm

900 mm

Height

600 mm

Uniclass

Pr_40_30_29_84 Street and site benchesPrimary

CAWS

Q50/33 Benches

Q50/220 Benches

Specification data - Street and site benches

Length

900 mm.

Base

Sub-surface mounted.

Material

Precast concrete.

Finish as delivered

Self finished.

Colours

Silver grey.

Accessories

Guidance for specification option:

Products can be used in conjunction with street furniture elements from the Verso street furniture range, consult manufacturer and insert requirements or omit.

Width

900 mm.

Overall height

600 mm.

Height

550 mm.

Weight

542.5 kg.

Manufacturer guidance

Overall module weight.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Literature

HVM Landscape Protection (Hostile Vehicle Mitigation)

HVM Landscape Protection (Hostile Vehicle Mitigation)
