Application

  • Protective seating for use in public spaces.
  • Landscape protection.


Description

Vehicular-borne threats are a reality in many modern urban environments and with the RhinoGuard® Igneo Protective Seat, safety and security combined with a subtle visual appeal can be achieved.


Crash tested on two occasions, pinpointing different locations of the seat, Igneo can successfully withstand impact from a 7.5 tonne vehicle travelling at 40 mph.


Manufactured using precast concrete, Igneo is available in four colour variations, all finished with an anti-graffiti coating. The optional armrests are manufactured using Ferrocast®, known for its resilience. These are available in a range of RAL colours in order to achieve the look you desire.


Igneo has been crash tested twice and the security classifications are V/7500(N2)/64/90:3.7/0.0 and V/7500(N2)/64/90:3.5/0.0.


*Igneo can be extended to the length required with 3017 mm being the minimum length.


Features and benefits:

  • Modular system
  • Crash-tested to PAS standards
  • Durable and low maintenance
  • Four colours available
  • Anti-graffiti coating


General information

Color

Cream

Grey

Black

Blue

Yellow

Show more

Finish

Etched

Material

Precast concrete

Polyurethane (PUR)

Shape

Other

Length

1036 mm

1093 mm

3017 mm

Width

1240 mm

Height

874 mm

Uniclass

Pr_40_30_29_85 Street and site seatsPrimary

CAWS

Q50/225 Seats

Q50/34 Seats

Specification data - Street and site seats

Length

1093 mm.

3017 mm.

1036 mm.

Base

Root.

Material

Precast concrete.

Finish as delivered

Etched.

Colours

Conservation charcoal.

Silver grey.

Anthracite.

Conservation silver grey.

Accessories

Guidance for specification option:

Consult manufacturer and insert requirement or omit.

Armrest

Not required.

Required.

Colour/ Finish

Not required.

RAL 7038.

Traffic Yellow RAL 1023.

Traffic Red RAL 3020.

Pure White RAL 9010.

Show more

Overall height

1159 mm.

Height (above ground)

874 mm.

Height

474 mm.

Width

1240 mm.

Weight

1000 kg.

1420 kg.

1200 kg.

Orientation

Not applicable.

Left hand.

Right hand.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom
