Resin Flooring System FasTop SL45 SRA

Verified by manufacturer 3 months ago

Sherwin-Williams Third party certifications:
  • European Technical Approvals

    European Technical Approvals

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

A 4–5 mm thick polyurethane cement self-levelling resin floor system with an aggregate scatter and seal coat to provide a very heavy duty textured finish.

Jump to:
+44 (0)1204 521771 Website

Application

Self-smoothing resin floor system suitable for use in:

  • Food manufacture and processing.
  • Brewing and beverage.
  • Dairies.
  • Commercial kitchens.
  • Pharmaceutical and chemical plant processing.
  • Abattoirs and meat processing facilities.
  • Heavy duty plant and traffic areas.

Description

A 4–5 mm-thick polyurethane cement self-levelling resin floor system with an aggregate scatter and seal coat to provide a very heavy duty textured finish with resistance against chemical attack, hot water and abrasion. A food certified system ideal where maximum hygienic standards are required with a non-slip finish.


System includes:

  • Substrate.
  • Primer: Resuprime ST/ MTV.
  • Screed: FasTop Multi SL45.
  • Broadcast: Aggregate scatter.
  • Topcoat: FasTop Multi T150.


Features and benefits:

  • High chemical resistance.
  • Slip resistant texture.
  • Resistance to hot water.
  • Self-sealing.
  • Extremely hard wearing.
  • Non dusting.
  • Matt finish.

General information

Color

Finish

Matt

Smooth

Anti-microbial

Anti-slip

Anti-skid

Material

Polyurethane

Guidance for specification option:

Polyurethane resin.

Resin

Water-borne

Warranty description

Six year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/10 Resin flooring

M12/110 Resin flooring

Specification data - Resin flooring systems

Substrate

-

Testing

Moisture content to BS 8204.

Preparation

Preparation of existing substrates.

Guidance for specification option:

Substrates must be clean, sound, dry and free of surface laitance with a minimum strength of 25 N/mm². Mechanically prepare substrate to provide a surface texture that will function as a key for the resin. Remove all dust and debris. Repair significant mechancial damage, pitting and cracks.

Preparation of new substrates.

Primer

Resuprime ST/ MTV.

Resin coating primers.

Resin flooring

FasTop Multi SL45.

Guidance for specification option:

Screed.

Quartz sand.

Guidance for specification option:

Broadcast.

Resuthane T100.

Guidance for specification option:

Top coat.

Flow applied flooring.

Heavy-duty flow-applied flooring.

Multilayer flooring.

Movement joints

-

Type

Continue functioning subfloor joints.

Guidance for specification option:

Through the resin flooring system and fill with Epo-Flex VJ.

Resin flooring strip movement joints.

Resin skirtings and upstands

FasTop Multi WR.

Guidance for specification option:

Coved skirtings.

Render-grade resins.

Execution

Workmanship.

Application of primers.

Surface abrading and polishing.

Applying surface sealers.

Applying surface finishes.

Retention of resin edges.

Installing strip movement joints.

System thickness

4—5 mm.

Hardness

To BS ISO 7619-1, 80.

Guidance for specification option:

After 24 hours.

Manufacturer guidance

Shore D.

Abrasion resistance

To BS EN 13892-4, AR 0.5.

CompressiveStrength

To BS EN ISO 604, 54 MPa.

Flexural strength

To BS EN ISO 178:2010+A1, 14 N/mm².

Bond strength

To BS EN 13892-8, >3 N/mm².

Impact resistance

To BS EN ISO 6272-1, >4.

Temperature resistance

90°C.

Guidance for specification option:

At 5 mm.

Manufacturer guidance

Tolerant of temperatures up to:

Reaction to fire (to EN 13501-1)

Bfl–s1.

Chemical resistance

Excellent.

UV stabilization

No.

VOC content

≤84 g/L.

Guidance for specification option:

Varies depending on product.

Coverage

Up to 20 m².

Guidance for specification option:

Varies depending on the product.

Cure time

8 hours to 8 days.

Guidance for specification option:

Depends on traffic conditions and temperature.

Application temperature

5—25°C.

Guidance for specification option:

A relative humidity (ERH) <90%.

Colour

Black.

Blue.

Buff.

Green.

Marigold.

Show more

Performance

-

Manufacturer guidance

  • Slip resistance.
  • Durability.
  • Water and vapour resistance.

Testing

-

Manufacturer guidance

  • Testing slip resistance.
  • Testing bond strength.
  • Verification of performance.

Sustainability data

Country of product manufacture

United Kingdom

Third party certifications

European Technical Approvals

European Technical Approvals

HACCP International

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001

Literature

A guide to FasTop polyurethane cement flooring systems for the Food and Beverage sector and for heavy industrial environments

A guide to FasTop polyurethane cement flooring systems for the Food and Beverage sector and for heavy industrial environments

A guide to Sherwin-Williams Food & Beverage Resin Flooring

A guide to Sherwin-Williams Food & Beverage Resin Flooring

Colour Chart - FasTop polyurethane screed systems

Colour Chart - FasTop polyurethane screed systems

Resin flooring FasTop SL45 SRA screed system

Resin flooring FasTop SL45 SRA screed system
